library: libGraf
#include "TPavesText.h"

TPavesText


class description - source file - inheritance tree (.pdf)

class TPavesText : public TPaveText

Inheritance Chart:
TObject
TAttLine
TAttFill
<-
TBox
<-
TPave
TAttText
<-
TPaveText
<-
TPavesText

    public:
TPavesText() TPavesText(Double_t x1, Double_t y1, Double_t x2, Double_t y2, Int_t npaves = 5, Option_t* option = "br") TPavesText(const TPavesText& pavestext) virtual ~TPavesText() static TClass* Class() virtual void Draw(Option_t* option = "") virtual Int_t GetNpaves() virtual TClass* IsA() const TPavesText& operator=(const TPavesText&) virtual void Paint(Option_t* option = "") virtual void SavePrimitive(ofstream& out, Option_t* option) virtual void SetNpaves(Int_t npaves = 5) virtual void ShowMembers(TMemberInspector& insp, char* parent) virtual void Streamer(TBuffer& b) void StreamerNVirtual(TBuffer& b)

Data Members


    protected:
Int_t fNpaves Number of stacked paves

Class Description

  A PavesText is a PaveText (see TPaveText) with several stacked paves.
/* */


TPavesText(): TPaveText()
 Pavestext default constructor.

TPavesText(Double_t x1, Double_t y1,Double_t x2, Double_t y2, Int_t npaves,Option_t *option) :TPaveText(x1,y1,x2,y2,option)
 Pavestext normal constructor.

 The PavesText is by default defined bith bordersize=1 and option ="br".

~TPavesText()
 Pavestext default destructor.

TPavesText(const TPavesText &pavestext) : TPaveText()
 Pavestext copy constructor.

void Draw(Option_t *option)
 Draw this pavestext with its current attributes.

void Paint(Option_t *option)
 Paint this pavestext with its current attributes.

void SavePrimitive(ofstream &out, Option_t *)
 Save primitive as a C++ statement(s) on output stream out



Inline Functions


              Int_t GetNpaves()
               void SetNpaves(Int_t npaves = 5)
            TClass* Class()
            TClass* IsA() const
               void ShowMembers(TMemberInspector& insp, char* parent)
               void Streamer(TBuffer& b)
               void StreamerNVirtual(TBuffer& b)
        TPavesText& operator=(const TPavesText&)


Author: Rene Brun 19/11/95
Last update: root/graf:$Name: $:$Id: TPavesText.cxx,v 1.8 2005/11/21 13:57:42 couet Exp $
