TGeoVoxelFinder

class TGeoVoxelFinder : public TObject

    public:

       TGeoVoxelFinder TGeoVoxelFinder()
       TGeoVoxelFinder TGeoVoxelFinder(TGeoVolume* vol)
       TGeoVoxelFinder TGeoVoxelFinder(const TGeoVoxelFinder&)
          virtual void ~TGeoVoxelFinder()
          virtual void BuildVoxelLimits()
        static TClass* Class()
                  void CreateCheckList()
                  void DaughterToMother(Int_t id, Double_t* local, Double_t* master) const
      virtual Double_t Efficiency()
          virtual void FindOverlaps(Int_t inode) const
        virtual Int_t* GetCheckList(Double_t* point, Int_t& nelem)
                Bool_t GetIndices(Double_t* point)
                 Int_t GetNcandidates() const
        virtual Bool_t GetNextIndices(Double_t* point, Double_t* dir)
        virtual Int_t* GetNextVoxel(Double_t* point, Double_t* dir, Int_t& ncheck)
                 Int_t GetPriority(Int_t iaxis) const
                Bool_t Intersect(Int_t n1, Int_t* array1, Int_t n2, Int_t* array2, Int_t n3, Int_t* array3, Int_t& nf, Int_t* result)
                  void IntersectAndStore(Int_t n1, Int_t* array1, Int_t n2, Int_t* array2, Int_t n3, Int_t* array3)
       virtual TClass* IsA() const
          virtual void Print(Option_t* option) const
                  void PrintVoxelLimits(Double_t* point) const
          virtual void ShowMembers(TMemberInspector& insp, char* parent)
          virtual void SortAll(Option_t* option)
                  void SortCrossedVoxels(Double_t* point, Double_t* dir)
          virtual void Streamer(TBuffer& b)
                  void StreamerNVirtual(TBuffer& b)
                Bool_t Union(Int_t n1, Int_t* array1, Int_t n2, Int_t* array2, Int_t n3, Int_t* array3)
          virtual void Voxelize(Option_t* option)

Data Members

    protected:

      TGeoVolume* fVolume        volume to which applies
            Int_t fNcandidates   ! number of candidates
            Int_t fCurrentVoxel  ! index of current voxel in sorted list
            Int_t fIbx           number of different boundaries on X axis
            Int_t fIby           number of different boundaries on Y axis
            Int_t fIbz           number of different boundaries on Z axis
            Int_t fNboxes        length of boxes array
            Int_t fNox           length of array of X offsets
            Int_t fNoy           length of array of Y offsets
            Int_t fNoz           length of array of Z offsets
            Int_t fNx            length of array of X voxels
            Int_t fNy            length of array of Y voxels
            Int_t fNz            length of array of Z voxels
            Int_t fPriority[3]   priority for each axis
            Int_t fSlices[3]     ! slice indices for current voxel
        Double_t* fBoxes         [fNboxes] list of bounding boxes
        Double_t* fXb            [fIbx] ordered array of X box boundaries
        Double_t* fYb            [fIby] ordered array of Y box boundaries
        Double_t* fZb            [fIbz] ordered array of Z box boundaries
           Int_t* fOBx           [fNox] offsets of daughter indices for slices X
           Int_t* fOBy           [fNoy] offsets of daughter indices for slices Y
           Int_t* fOBz           [fNoz] offsets of daughter indices for slices Z
           Int_t* fIndX          [fNx] indices of daughters inside boundaries X
           Int_t* fIndY          [fNy] indices of daughters inside boundaries Y
           Int_t* fIndZ          [fNz] indices of daughters inside boundaries Z
           Int_t* fCheckList     ! list of candidates

See also

TGeoCylVoxels

Class Description

 Full description with examples and pictures





/*



*/

 Default constructor

 Default constructor

 Destructor
   printf("deleting finder of %sn", fVolume->GetName());

 build the array of bounding boxes of the nodes inside

 Initializes check list.

 convert a point from the local reference system of node id to reference
 system of mother volume

--- Compute voxelization efficiency.

 create the list of nodes for which the bboxes overlap with inode's bbox

 Getindices for current slices on x, y, z

 Get indices for next voxel

 get the list in the next voxel crossed by a ray

 get the list of daughter indices for which point is inside their bbox

 get the list of new candidates for the next voxel crossed by current ray
   printf("### GetNextVoxeln");

 make the union of fCheckList with the result of the intersection of the 3 arrays
 first reset bits

 first reset bits

 return the intersection of three ordered lists

 order bounding boxes along x, y, z

 print the voxel containing point

 Voxelize attached volume according to option

Inline Functions

                  Int_t GetPriority(Int_t iaxis) const
                  Int_t GetNcandidates() const
                TClass* Class()
                TClass* IsA() const
                   void ShowMembers(TMemberInspector& insp, char* parent)
                   void Streamer(TBuffer& b)
                   void StreamerNVirtual(TBuffer& b)
        TGeoVoxelFinder TGeoVoxelFinder(const TGeoVoxelFinder&)
