df042_ThreadSafeRNG.C File Reference

Detailed Description

Usage of multithreading mode with random generators.

This example illustrates how to define functions that generate random numbers and use them in an RDataFrame computation graph in a thread-safe way.

Using only one random number generator in an application running with ROOT::EnableImplicitMT() is a common pitfall. This pitfall creates race conditions resulting in a distorted random distribution. In the example, this issue is solved by creating one random number generator per RDataFrame processing slot, thus allowing for parallel and thread-safe access. The example also illustrates the difference between non-deterministic and deterministic random number generation.


#include <algorithm>
#include <iostream>
#include <memory>
#include <thread>
#include <TCanvas.h>
#include <ROOT/RDataFrame.hxx>

#include "df042_ThreadSafeRNG.hxx"

// Canvas that should survive the running of this macro
auto myCanvas = std::make_unique<TCanvas>("myCanvas", "myCanvas", 1000, 500);

void df042_ThreadSafeRNG()
{
   myCanvas->Divide(3, 1);

   unsigned int nEntries{10000000};

   // 1. Single thread for reference
   auto df1 = ROOT::RDataFrame(nEntries).Define("x", GetNormallyDistributedNumberFromGlobalGenerator);
   auto h1 = df1.Histo1D({"h1", "Single thread (no MT)", 1000, -4, 4}, {"x"});
   myCanvas->cd(1);
   h1->Draw();

   // 2. One generator per RDataFrame slot, with random_device seeding
   // Notes and Caveats:
   // - How many numbers are drawn from each generator is not deterministic
   //   and the result is not deterministic between runs.
   unsigned int nSlots{std::max(2u, std::thread::hardware_concurrency() / 4u)};
   ROOT::EnableImplicitMT(nSlots);
   // Before running the RDataFrame computation graph, we reinitialize the generators (one per slot), so they can
   // be used accordingly during the execution.
   ReinitializeGenerators(nSlots);
   auto df2 = ROOT::RDataFrame(nEntries).DefineSlot("x", GetNormallyDistributedNumberPerSlotGenerator);
   auto h2 = df2.Histo1D({"h2", "Thread-safe (MT, non-deterministic)", 1000, -4, 4}, {"x"});
   myCanvas->cd(2);
   h2->Draw();

   // 3. One generator per RDataFrame slot, with entry seeding
   // Notes and Caveats:
   // - With RDataFrame(INTEGER_NUMBER) constructor (as in the example),
   //   the result is deterministic and identical on every run
   // - With RDataFrame(TTree) constructor, the result is not guaranteed to be deterministic.
   //   To make it deterministic, use something from the dataset to act as the event identifier
   //   instead of rdfentry_, and use it as a seed.

   // Before running the RDataFrame computation graph, we reinitialize the generators (one per slot), so they can
   // be used accordingly during the execution.
   ReinitializeGenerators(nSlots);
   auto df3 = ROOT::RDataFrame(nEntries).DefineSlotEntry("x", GetNormallyDistributedNumberPerSlotGeneratorForEntry);
   auto h3 = df3.Histo1D({"h3", "Thread-safe (MT, deterministic)", 1000, -4, 4}, {"x"});
   myCanvas->cd(3);
   h3->Draw();

   std::cout << std::fixed << std::setprecision(3) << "Final distributions                : " << "Mean " << " +- "
             << "StdDev" << std::endl;
   std::cout << std::fixed << std::setprecision(3) << "Theoretical                        : " << "0.000" << " +- "
             << "1.000" << std::endl;
   std::cout << std::fixed << std::setprecision(3) << "Single thread (no MT)              : " << h1->GetMean() << " +- "
             << h1->GetStdDev() << std::endl;
   std::cout << std::fixed << std::setprecision(3) << "Thread-safe (MT, non-deterministic): " << h2->GetMean() << " +- "
             << h2->GetStdDev() << std::endl;
   std::cout << std::fixed << std::setprecision(3) << "Thread-safe (MT, deterministic)    : " << h3->GetMean() << " +- "
             << h3->GetStdDev() << std::endl;
}

Final distributions                : Mean  +- StdDev
Theoretical                        : 0.000 +- 1.000
Single thread (no MT)              : 0.000 +- 0.999
Thread-safe (MT, non-deterministic): -0.000 +- 0.999
Thread-safe (MT, deterministic)    : 0.000 +- 1.000

Date

February 2026

Author

Bohdan Dudar (JGU Mainz), Fernando Hueso-González (IFIC, CSIC-UV), Vincenzo Eduardo Padulano (CERN)

Definition in file df042_ThreadSafeRNG.C.
