Define a Pie Chart.
| Option | Description |
|---|---|
| "R" | Print the labels along the central "R"adius of slices. |
| "T" | Print the label in a direction "T"angent to circle that describes the TPie. |
| "SC" | Paint the labels with the "S"ame "C"olor as the slices. |
| "3D" | Draw the pie-chart with a pseudo 3D effect. |
| "NOL" | No OutLine: Don't draw the slices' outlines, any property over the slices' line is ignored. |
| ">" | Sort the slices in increasing order. |
| "<" | Sort the slices in decreasing order. |
After the use of > or < options the internal order of the TPieSlices is changed.
The labels' format can be changed with TPie::SetLabelFormat().
The format string must contain one of these modifiers:
| Modifier | Description |
|---|---|
| "%txt" | to print the text label associated with the slice |
| "%val" | to print the numeric value of the slice |
| "%frac" | to print the relative fraction of this slice |
| "%perc" | to print the % of this slice |
Example:
The numeric format in the label can be changed with TPie::SetFractionFormat. The numeric format the slices' values can be changed with TPie::SetValueFormat. The numeric format for the percent value of a slice can be changed with TPie::SetPercentFormat.
If the colors are not specified (nullptr) they are automatically taken from the current color palette as shown in the following example.
More complex example:
Public Types | |
| enum | { kIsOnHeap = 0x01000000 , kNotDeleted = 0x02000000 , kZombie = 0x04000000 , kInconsistent = 0x08000000 , kBitMask = 0x00ffffff } |
| enum | { kSingleKey = (1ULL << ( 0 )) , kOverwrite = (1ULL << ( 1 )) , kWriteDelete = (1ULL << ( 2 )) } |
| enum | EDeprecatedStatusBits { kObjInCanvas = (1ULL << ( 3 )) } |
| enum | EStatusBits { kCanDelete = (1ULL << ( 0 )) , kMustCleanup = (1ULL << ( 3 )) , kIsReferenced = (1ULL << ( 4 )) , kHasUUID = (1ULL << ( 5 )) , kCannotPick = (1ULL << ( 6 )) , kNoContextMenu = (1ULL << ( 8 )) , kInvalidObject = (1ULL << ( 13 )) } |
Public Member Functions | |
| TPie () | |
| Default constructor. | |
| TPie (const char *, const char *, Int_t) | |
| This constructor creates a pie chart when only the number of the slices is known. | |
| TPie (const char *, const char *, Int_t, Double_t *, Int_t *cols=nullptr, const char *lbls[]=nullptr) | |
| Normal constructor. | |
| TPie (const char *, const char *, Int_t, Float_t *, Int_t *cols=nullptr, const char *lbls[]=nullptr) | |
| Normal constructor (Float_t). | |
| TPie (const TH1 *h) | |
| Constructor from a TH1. | |
| TPie (const TPie &) | |
| Copy constructor. | |
| ~TPie () override | |
| Destructor. | |
| void | AbstractMethod (const char *method) const |
| Call this function within a function that you don't want to define as purely virtual, in order not to force all users deriving from that class to implement that maybe (on their side) unused function; but at the same time, emit a run-time warning if they try to call it, telling that it is not implemented in the derived class: action must thus be taken on the user side to override it. | |
| virtual void | AppendPad (Option_t *option="") |
| Append graphics object to current pad. | |
| virtual void | Browse (TBrowser *b) |
| Browse object. May be overridden for another default action. | |
| ULong_t | CheckedHash () |
| Check and record whether this class has a consistent Hash/RecursiveRemove setup (*) and then return the regular Hash value for this object. | |
| virtual const char * | ClassName () const |
| Returns name of class to which the object belongs. | |
| void | Clear (Option_t *option="") override |
| Set name and title to empty strings (""). | |
| TObject * | Clone (const char *newname="") const override |
| Make a clone of an object using the Streamer facility. | |
| Int_t | Compare (const TObject *obj) const override |
| Compare two TNamed objects. | |
| void | Copy (TAttText &atttext) const |
| Copy this text attributes to a new TAttText. | |
| void | Copy (TObject &named) const override |
| Copy this to obj. | |
| virtual void | Delete (Option_t *option="") |
| Delete this object. | |
| Int_t | DistancetoPrimitive (Int_t px, Int_t py) override |
| Evaluate the distance to the chart in gPad. | |
| Int_t | DistancetoSlice (Int_t, Int_t) |
| Returns the slice number at the pixel position (px,py). | |
| void | Draw (Option_t *option="l") override |
| Draw the pie chart. | |
| virtual void | DrawClass () const |
| Draw class inheritance tree of the class to which this object belongs. | |
| virtual TObject * | DrawClone (Option_t *option="") const |
Draw a clone of this object in the current selected pad with: gROOT->SetSelectedPad(c1). | |
| virtual void | Dump () const |
| Dump contents of object on stdout. | |
| virtual void | Error (const char *method, const char *msgfmt,...) const |
| Issue error message. | |
| virtual void | Execute (const char *method, const char *params, Int_t *error=nullptr) |
| Execute method on this object with the given parameter string, e.g. | |
| virtual void | Execute (TMethod *method, TObjArray *params, Int_t *error=nullptr) |
| Execute method on this object with parameters stored in the TObjArray. | |
| void | ExecuteEvent (Int_t, Int_t, Int_t) override |
| Execute the mouse events. | |
| virtual void | Fatal (const char *method, const char *msgfmt,...) const |
| Issue fatal error message. | |
| virtual void | FillBuffer (char *&buffer) |
| Encode TNamed into output buffer. | |
| virtual TObject * | FindObject (const char *name) const |
| Must be redefined in derived classes. | |
| virtual TObject * | FindObject (const TObject *obj) const |
| Must be redefined in derived classes. | |
| Float_t | GetAngle3D () |
| Double_t | GetAngularOffset () |
| virtual Option_t * | GetDrawOption () const |
| Get option used by the graphics system to draw this object. | |
| Int_t | GetEntries () |
| Int_t | GetEntryFillColor (Int_t) |
| Return the color of the slice number "i". | |
| Int_t | GetEntryFillStyle (Int_t) |
| Return the style use to fill the slice number "i". | |
| const char * | GetEntryLabel (Int_t) |
| Returns the label of the entry number "i". | |
| Int_t | GetEntryLineColor (Int_t) |
| Return the line color used to outline thi "i" slice. | |
| Int_t | GetEntryLineStyle (Int_t) |
| Return the style used to outline thi "i" slice. | |
| Int_t | GetEntryLineWidth (Int_t) |
| Return the line width used to outline thi "i" slice. | |
| Double_t | GetEntryRadiusOffset (Int_t) |
| Return the radial offset's value for the slice number "i". | |
| Double_t | GetEntryVal (Int_t) |
| Return the value associated with the slice number "i". | |
| const char * | GetFractionFormat () |
| Double_t | GetHeight () |
| virtual const char * | GetIconName () const |
| Returns mime type name of object. | |
| const char * | GetLabelFormat () |
| Float_t | GetLabelsOffset () |
| TLegend * | GetLegend () |
| If created before by Paint option or by MakeLegend method return the pointer to the legend, otherwise return 0;. | |
| const char * | GetName () const override |
| Returns name of object. | |
| virtual char * | GetObjectInfo (Int_t px, Int_t py) const |
| Returns string containing info about the object at position (px,py). | |
| virtual Option_t * | GetOption () const |
| const char * | GetPercentFormat () |
| Double_t | GetRadius () |
| TPieSlice * | GetSlice (Int_t i) |
| Return the reference to the slice of index 'id'. | |
| virtual Short_t | GetTextAlign () const |
| Return the text alignment. | |
| virtual Float_t | GetTextAngle () const |
| Return the text angle. | |
| virtual Color_t | GetTextColor () const |
| Return the text color. | |
| virtual Font_t | GetTextFont () const |
| Return the text font. | |
| virtual Float_t | GetTextSize () const |
| Return the text size. | |
| virtual Float_t | GetTextSizePercent (Float_t size) |
| Return the text in percent of the pad size. | |
| virtual Float_t | GetTextSizePixels (TVirtualPad &pad) const |
| Return the text size in pixels for specified pad. | |
| virtual Float_t | GetTextSizeRelative (TVirtualPad &pad) const |
| Return the text size in relative units. | |
| const char * | GetTitle () const override |
| Returns title of object. | |
| virtual UInt_t | GetUniqueID () const |
| Return the unique object id. | |
| const char * | GetValueFormat () |
| Double_t | GetX () |
| Double_t | GetY () |
| virtual Bool_t | HandleTimer (TTimer *timer) |
| Execute action in response of a timer timing out. | |
| ULong_t | Hash () const override |
| Return hash value for this object. | |
| Bool_t | HasInconsistentHash () const |
| Return true is the type of this object is known to have an inconsistent setup for Hash and RecursiveRemove (i.e. | |
| virtual void | Info (const char *method, const char *msgfmt,...) const |
| Issue info message. | |
| virtual Bool_t | InheritsFrom (const char *classname) const |
| Returns kTRUE if object inherits from class "classname". | |
| virtual Bool_t | InheritsFrom (const TClass *cl) const |
| Returns kTRUE if object inherits from TClass cl. | |
| virtual void | Inspect () const |
| Dump contents of this object in a graphics canvas. | |
| void | InvertBit (UInt_t f) |
| TClass * | IsA () const override |
| Bool_t | IsDestructed () const |
| IsDestructed. | |
| virtual Bool_t | IsEqual (const TObject *obj) const |
| Default equal comparison (objects are equal if they have the same address in memory). | |
| virtual Bool_t | IsFolder () const |
| Returns kTRUE in case object contains browsable objects (like containers or lists of other objects). | |
| R__ALWAYS_INLINE Bool_t | IsOnHeap () const |
| Bool_t | IsSortable () const override |
| R__ALWAYS_INLINE Bool_t | IsZombie () const |
| void | ls (Option_t *option="") const override |
| List TNamed name and title. | |
| TLegend * | MakeLegend (Double_t x1=.65, Double_t y1=.65, Double_t x2=.95, Double_t y2=.95, const char *leg_header="") |
| This method create a legend that explains the contents of the slice for this pie-chart. | |
| void | MakeSlices (Bool_t force=kFALSE) |
| Make the slices. | |
| void | MayNotUse (const char *method) const |
| Use this method to signal that a method (defined in a base class) may not be called in a derived class (in principle against good design since a child class should not provide less functionality than its parent, however, sometimes it is necessary). | |
| virtual void | Modify () |
| Change current text attributes if necessary. | |
| virtual void | ModifyOn (TVirtualPad &pad) |
| Change current text attributes if necessary on specified pad. | |
| virtual Bool_t | Notify () |
| This method must be overridden to handle object notification (the base implementation is no-op). | |
| void | Obsolete (const char *method, const char *asOfVers, const char *removedFromVers) const |
| Use this method to declare a method obsolete. | |
| void | operator delete (void *, size_t) |
| Operator delete for sized deallocation. | |
| void | operator delete (void *ptr) |
| Operator delete. | |
| void | operator delete (void *ptr, void *vp) |
| Only called by placement new when throwing an exception. | |
| void | operator delete[] (void *, size_t) |
| Operator delete [] for sized deallocation. | |
| void | operator delete[] (void *ptr) |
| Operator delete []. | |
| void | operator delete[] (void *ptr, void *vp) |
| Only called by placement new[] when throwing an exception. | |
| void * | operator new (size_t sz) |
| void * | operator new (size_t sz, void *vp) |
| void * | operator new[] (size_t sz) |
| void * | operator new[] (size_t sz, void *vp) |
| void | Paint (Option_t *) override |
| Paint a Pie chart in a canvas. | |
| virtual void | Pop () |
| Pop on object drawn in a pad to the top of the display list. | |
| void | Print (Option_t *option="") const override |
| Print TNamed name and title. | |
| virtual Int_t | Read (const char *name) |
| Read contents of object with specified name from the current directory. | |
| virtual void | RecursiveRemove (TObject *obj) |
| Recursively remove this object from a list. | |
| virtual void | ResetAttText (Option_t *toption="") |
| Reset this text attributes to default values. | |
| void | ResetBit (UInt_t f) |
| virtual void | SaveAs (const char *filename="", Option_t *option="") const |
| Save this object in the file specified by filename. | |
| void | SavePrimitive (std::ostream &out, Option_t *opts="") override |
| Save primitive as a C++ statement(s) on output stream out. | |
| virtual void | SaveTextAttributes (std::ostream &out, const char *name, Int_t alidef=12, Float_t angdef=0, Int_t coldef=1, Int_t fondef=61, Float_t sizdef=1) |
| Save text attributes as C++ statement(s) on output stream out. | |
| void | SetAngle3D (Float_t val=30.) |
| Set the value of for the pseudo 3D view angle, in degree. | |
| void | SetAngularOffset (Double_t) |
| Set the global angular offset for slices in degree [0,360]. | |
| void | SetBit (UInt_t f) |
| void | SetBit (UInt_t f, Bool_t set) |
| Set or unset the user status bits as specified in f. | |
| void | SetCircle (Double_t x=.5, Double_t y=.5, Double_t rad=.4) |
| Set the coordinates of the circle that describe the pie: | |
| virtual void | SetDrawOption (Option_t *option="") |
| Set drawing option for object. | |
| void | SetEntryFillColor (Int_t, Int_t) |
| Set the color for the slice "i". | |
| void | SetEntryFillStyle (Int_t, Int_t) |
| Set the fill style for the "i" slice. | |
| void | SetEntryLabel (Int_t, const char *text="Slice") |
| Set slice number "i" label. | |
| void | SetEntryLineColor (Int_t, Int_t) |
| Set the color for the slice's outline. "i" is the slice number. | |
| void | SetEntryLineStyle (Int_t, Int_t) |
| Set the style for the slice's outline. "i" is the slice number. | |
| void | SetEntryLineWidth (Int_t, Int_t) |
| Set the width of the slice's outline. "i" is the slice number. | |
| void | SetEntryRadiusOffset (Int_t, Double_t) |
| Set the distance, in the direction of the radius of the slice. | |
| void | SetEntryVal (Int_t, Double_t) |
| Set the value of a slice. | |
| void | SetFillColors (Int_t *) |
| Set the fill colors for all the TPie's slices. | |
| void | SetFractionFormat (const char *) |
| Set numeric format in the label, is used if the label format there is the modifier frac, in this case the value is printed using this format. | |
| void | SetHeight (Double_t val=.08) |
| Set the height, in pixel, for the piechart if is drawn using the pseudo-3d mode. | |
| void | SetLabelFormat (const char *) |
| This method is used to customize the label format. | |
| void | SetLabels (const char *[]) |
| Set the labels for all the slices. | |
| void | SetLabelsOffset (Float_t) |
| Set the distance between the label end the external line of the TPie. | |
| virtual void | SetName (const char *name) |
| Set the name of the TNamed. | |
| virtual void | SetNameTitle (const char *name, const char *title) |
| Set all the TNamed parameters (name and title). | |
| void | SetPercentFormat (const char *) |
| Set the numeric format for the percent value of a slice, default: %3.1f. | |
| void | SetRadius (Double_t) |
| Set the pie chart's radius' value. | |
| virtual void | SetTextAlign (Short_t align=11) |
| Set the text alignment. | |
| virtual void | SetTextAngle (Float_t tangle=0) |
| Set the text angle. | |
| virtual void | SetTextAttributes () |
| Invoke the DialogCanvas Text attributes. | |
| virtual void | SetTextColor (Color_t tcolor=1) |
| Set the text color. | |
| void | SetTextColor (TColorNumber lcolor) |
| virtual void | SetTextColorAlpha (Color_t tcolor, Float_t talpha) |
| Set a transparent text color. | |
| virtual void | SetTextFont (Font_t tfont=62) |
| Set the text font. | |
| virtual void | SetTextSize (Float_t tsize=1) |
| Set the text size. | |
| virtual void | SetTextSizePixels (Int_t npixels) |
| Set the text size in pixel. | |
| virtual void | SetTitle (const char *title="") |
| Set the title of the TNamed. | |
| virtual void | SetUniqueID (UInt_t uid) |
| Set the unique object id. | |
| void | SetValueFormat (const char *) |
| Set the numeric format the slices' values. | |
| void | SetX (Double_t) |
| Set X value. | |
| void | SetY (Double_t) |
| Set Y value. | |
| virtual Int_t | Sizeof () const |
| Return size of the TNamed part of the TObject. | |
| void | SortSlices (Bool_t amode=kTRUE, Float_t merge_thresold=.0) |
| This method, mainly intended for internal use, ordered the slices according their values. | |
| void | Streamer (TBuffer &) override |
| Stream an object of class TObject. | |
| void | StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b) |
| virtual void | SysError (const char *method, const char *msgfmt,...) const |
| Issue system error message. | |
| R__ALWAYS_INLINE Bool_t | TestBit (UInt_t f) const |
| Int_t | TestBits (UInt_t f) const |
| virtual void | UseCurrentStyle () |
| Set current style settings in this object This function is called when either TCanvas::UseCurrentStyle or TROOT::ForceStyle have been invoked. | |
| virtual void | Warning (const char *method, const char *msgfmt,...) const |
| Issue warning message. | |
| virtual Int_t | Write (const char *name=nullptr, Int_t option=0, Int_t bufsize=0) |
| Write this object to the current directory. | |
| virtual Int_t | Write (const char *name=nullptr, Int_t option=0, Int_t bufsize=0) const |
| Write this object to the current directory. | |
Static Public Member Functions | |
| static TClass * | Class () |
| static const char * | Class_Name () |
| static constexpr Version_t | Class_Version () |
| static const char * | DeclFileName () |
| static Longptr_t | GetDtorOnly () |
| Return destructor only flag. | |
| static Bool_t | GetObjectStat () |
| Get status of object stat flag. | |
| static void | SetDtorOnly (void *obj) |
| Set destructor only flag. | |
| static void | SetObjectStat (Bool_t stat) |
| Turn on/off tracking of objects in the TObjectTable. | |
Protected Types | |
| enum | { kOnlyPrepStep = (1ULL << ( 3 )) } |
Protected Member Functions | |
| virtual void | DoError (int level, const char *location, const char *fmt, va_list va) const |
| Interface to ErrorHandler (protected). | |
| void | MakeZombie () |
| void | SavePrimitiveNameTitle (std::ostream &out, const char *variable_name) |
| Save object name and title into the output stream "out". | |
Static Protected Member Functions | |
| static void | SavePrimitiveConstructor (std::ostream &out, TClass *cl, const char *variable_name, const char *constructor_agrs="", Bool_t empty_line=kTRUE) |
| Save object constructor in the output stream "out". | |
| static void | SavePrimitiveDraw (std::ostream &out, const char *variable_name, Option_t *option=nullptr) |
| Save invocation of primitive Draw() method Skipped if option contains "nodraw" string. | |
| static TString | SavePrimitiveVector (std::ostream &out, const char *prefix, Int_t len, Double_t *arr, Int_t flag=0) |
| Save array in the output stream "out" as vector. | |
Protected Attributes | |
| Float_t | fAngle3D |
| The angle of the pseudo-3d view. | |
| Double_t | fAngularOffset |
| Offset angular offset for the first slice. | |
| TString | fFractionFormat |
| Rform numeric format for the fraction of a slice. | |
| Double_t | fHeight |
| Height of the slice in pixel. | |
| Bool_t | fIs3D |
| ! true if the pseudo-3d is enabled | |
| TString | fLabelFormat |
| Format format of the slices' label. | |
| Float_t | fLabelsOffset |
| LabelsOffset offset of label. | |
| TString | fName |
| Int_t | fNvals |
| Number of elements. | |
| TString | fPercentFormat |
| Pfrom numeric format for the percent of a slice. | |
| TPieSlice ** | fPieSlices {nullptr} |
| [fNvals] Slice array of this pie-chart | |
| Double_t | fRadius |
| Radius Pie radius. | |
| Short_t | fTextAlign |
| Text alignment. | |
| Float_t | fTextAngle |
| Text angle. | |
| Color_t | fTextColor |
| Text color. | |
| Font_t | fTextFont |
| Text font. | |
| Float_t | fTextSize |
| Text size. | |
| TString | fTitle |
| TString | fValueFormat |
| Vform numeric format for the value. | |
| Double_t | fX |
| X coordinate of the pie centre. | |
| Double_t | fY |
| Y coordinate of the pie centre. | |
Private Member Functions | |
| void | DrawGhost () |
| This method is for internal use. | |
| void | Init (Int_t np, Double_t ao, Double_t x, Double_t y, Double_t r) |
| Common initialization for all constructors. | |
Static Private Member Functions | |
| static void | AddToTObjectTable (TObject *) |
| Private helper function which will dispatch to TObjectTable::AddObj. | |
Private Attributes | |
| UInt_t | fBits |
| bit field status word | |
| TLegend * | fLegend {nullptr} |
| !Legend for this piechart | |
| Float_t * | fSlices {nullptr} |
| !Subdivisions of the slices | |
| Float_t | fSum |
| !Sum for the slice values | |
| UInt_t | fUniqueID |
| object unique identifier | |
Static Private Attributes | |
| static Longptr_t | fgDtorOnly = 0 |
| object for which to call dtor only (i.e. no delete) | |
| static Bool_t | fgObjectStat = kTRUE |
| if true keep track of objects in TObjectTable | |
#include <TPie.h>
| Enumerator | |
|---|---|
| kOnlyPrepStep | Used to request that the class specific implementation of This is just for example by TBufferMerger to request that the TTree inside the file calls |
|
inherited |
|
inherited |
| Enumerator | |
|---|---|
| kCanDelete | if object in a list can be deleted |
| kMustCleanup | if object destructor must call RecursiveRemove() |
| kIsReferenced | |
| kHasUUID | if object has a TUUID (its fUniqueID=UUIDNumber) |
| kCannotPick | if object in a pad cannot be picked |
| kNoContextMenu | if object does not want context menu |
| kInvalidObject | if object ctor succeeded but object should not be used |
| TPie::TPie | ( | const char * | name, |
| const char * | title, | ||
| Int_t | npoints, | ||
| Double_t * | vals, | ||
| Int_t * | colors = nullptr, | ||
| const char * | lbls[] = nullptr ) |
Normal constructor.
The 1st and 2nd parameters are the name of the object and its title.
The number of points passed at this point is used to allocate the memory.
Slices values are given as Double_t.
The 4th elements is an array containing, in double precision format, the value of each slice. It is also possible to specify the filled color of each slice. If the color array is not specified the slices are colored using a color sequence in the standard palette.
|
inherited |
Call this function within a function that you don't want to define as purely virtual, in order not to force all users deriving from that class to implement that maybe (on their side) unused function; but at the same time, emit a run-time warning if they try to call it, telling that it is not implemented in the derived class: action must thus be taken on the user side to override it.
In other word, this method acts as a "runtime purely virtual" warning instead of a "compiler purely virtual" error.
Definition at line 1149 of file TObject.cxx.
|
staticprivateinherited |
Private helper function which will dispatch to TObjectTable::AddObj.
Included here to avoid circular dependency between header files.
Definition at line 195 of file TObject.cxx.
|
virtualinherited |
Append graphics object to current pad.
In case no current pad is set yet, create a default canvas with the name "c1".
Definition at line 204 of file TObject.cxx.
|
virtualinherited |
Browse object. May be overridden for another default action.
Reimplemented in TASImage, TRecorder, TEfficiency, TGraph2D, TChain, TTree, TDirectory, TFolder, TMacro, TRemoteObject, TROOT, TStyle, TSystemDirectory, TSystemFile, TTask, TCollection, TPair, TBrowserObject, TBaseClass, TClass, TGeoManager, TGeoNode, TGeoVolume, TGeoOverlap, TGeoTrack, TCanvas, TPad, TAxis3D, TGeometry, TNode, TRootIconList, THbookBranch, THbookFile, THbookKey, TF1, TGraph, TH1, THnBase, ROOT::Internal::THnBaseBrowsable, THStack, TMultiDimFit, TMultiGraph, TPrincipal, TDirectoryFile, TKey, TKeyMapFile, TMapFile, TSPlot, TDatabasePDG, TGenerator, TParticleClassPDG, TApplicationRemote, RooPlot, TBranch, TVirtualBranchBrowsable, TCollectionPropertyBrowsable, TBranchClones, TBranchElement, TBranchObject, TBranchSTL, TLeaf, TNtuple, TNtupleD, TTreePerfStats, and ROOT::Experimental::XRooFit::xRooNode.
Definition at line 218 of file TObject.cxx.
|
inlineinherited |
Check and record whether this class has a consistent Hash/RecursiveRemove setup (*) and then return the regular Hash value for this object.
The intent is for this routine to be called instead of directly calling the function Hash during "insert" operations. See TObject::HasInconsistenTObjectHash();
(*) The setup is consistent when all classes in the class hierarchy that overload TObject::Hash do call ROOT::CallRecursiveRemoveIfNeeded in their destructor. i.e. it is safe to call the Hash virtual function during the RecursiveRemove operation.
|
virtualinherited |
Returns name of class to which the object belongs.
Definition at line 227 of file TObject.cxx.
|
overridevirtualinherited |
Set name and title to empty strings ("").
Reimplemented from TObject.
Reimplemented in TStreamerInfo, TVirtualStreamerInfo, TProcessID, TTask, TPrincipal, and TVirtualFitter.
Definition at line 63 of file TNamed.cxx.
Make a clone of an object using the Streamer facility.
If newname is specified, this will be the name of the new object.
Reimplemented from TObject.
Reimplemented in TStreamerInfo, and TTreeIndex.
Definition at line 73 of file TNamed.cxx.
Compare two TNamed objects.
Returns 0 when equal, -1 when this is smaller and +1 when bigger (like strcmp).
Reimplemented from TObject.
Reimplemented in TStructNodeProperty.
Definition at line 84 of file TNamed.cxx.
|
inherited |
Copy this text attributes to a new TAttText.
Definition at line 300 of file TAttText.cxx.
|
overridevirtualinherited |
Copy this to obj.
Reimplemented from TObject.
Reimplemented in TSystemDirectory, TSystemFile, TProfile, TProfile2D, TProfile3D, TPieSlice, TStyle, TText, and TXTRU.
Definition at line 93 of file TNamed.cxx.
|
virtualinherited |
Delete this object.
Typically called as a command via the interpreter. Normally use "delete" operator when object has been allocated on the heap.
Reimplemented in TDirectory, TDirectoryFile, TFile, TSystemDirectory, TSystemFile, TTreeViewer, TGItemContext, TCanvas, TGFrame, TGTextEdit, TAxis, RooLinkedList, TExMap, TObjectTable, TProtoClass, TKeySQL, TKeyXML, TQCommand, TBtree, TClonesArray, THashList, THashTable, TList, TMap, TObjArray, TOrdCollection, TRefArray, TListOfDataMembers, TListOfEnums, TListOfEnumsWithLock, TListOfFunctions, TListOfFunctionTemplates, TViewPubDataMembers, TViewPubFunctions, TThread, TKey, TMVA::Results, TTree, and TCollection.
Definition at line 268 of file TObject.cxx.
|
protectedvirtualinherited |
Interface to ErrorHandler (protected).
Reimplemented in TTreeViewer, and TThread.
Definition at line 1059 of file TObject.cxx.
|
overridevirtual |
Draw the pie chart.
The possible options are listed in the TPie::Paint() method.
Reimplemented from TObject.
|
virtualinherited |
Draw class inheritance tree of the class to which this object belongs.
If a class B inherits from a class A, description of B is drawn on the right side of description of A. Member functions overridden by B are shown in class A with a blue line crossing-out the corresponding member function. The following picture is the class inheritance tree of class TPaveLabel:
Reimplemented in TSystemDirectory, TSystemFile, and TGFrame.
Definition at line 308 of file TObject.cxx.
Draw a clone of this object in the current selected pad with: gROOT->SetSelectedPad(c1).
If pad was not selected - gPad will be used.
Reimplemented in TSystemDirectory, TSystemFile, TGFrame, TAxis, and TCanvas.
Definition at line 319 of file TObject.cxx.
|
private |
|
virtualinherited |
Dump contents of object on stdout.
Using the information in the object dictionary (class TClass) each data member is interpreted. If a data member is a pointer, the pointer value is printed
The following output is the Dump of a TArrow object:
Reimplemented in TSystemFile, TCollection, TClass, TGFrame, and TGPack.
Definition at line 367 of file TObject.cxx.
Issue error message.
Use "location" to specify the method where the error occurred. Accepts standard printf formatting arguments.
Reimplemented in TFitResult.
Definition at line 1098 of file TObject.cxx.
|
virtualinherited |
Execute method on this object with the given parameter string, e.g.
"3.14,1,\"text\"".
Reimplemented in TMethodCall, TCling, TInterpreter, ROOT::R::TRInterface, and TContextMenu.
Definition at line 378 of file TObject.cxx.
|
virtualinherited |
Execute method on this object with parameters stored in the TObjArray.
The TObjArray should contain an argv vector like:
Reimplemented in TCling, TMethodCall, TInterpreter, ROOT::R::TRInterface, and TContextMenu.
Definition at line 398 of file TObject.cxx.
Issue fatal error message.
Use "location" to specify the method where the fatal error occurred. Accepts standard printf formatting arguments.
Definition at line 1126 of file TObject.cxx.
|
virtualinherited |
Encode TNamed into output buffer.
Reimplemented in TKeySQL, TSQLFile, TKeyXML, TXMLFile, TDirectoryFile, TFile, and TKey.
Definition at line 103 of file TNamed.cxx.
Must be redefined in derived classes.
This function is typically used with TCollections, but can also be used to find an object by name inside this object.
Reimplemented in TListOfEnums, TMap, TDirectory, TFolder, TROOT, TListOfTypes, TListOfTypes, TBtree, TCollection, THashList, THashTable, TList, TObjArray, TListOfDataMembers, TListOfDataMembers, TListOfEnums, TListOfEnumsWithLock, TListOfFunctions, TListOfFunctionTemplates, TListOfFunctionTemplates, TViewPubDataMembers, TViewPubFunctions, TPad, TGeometry, THbookFile, TGraph, TGraph2D, TH1, RooAbsCollection, and RooLinkedList.
Definition at line 425 of file TObject.cxx.
Must be redefined in derived classes.
This function is typically used with TCollections, but can also be used to find an object inside this object.
Reimplemented in TMap, TDirectory, TFolder, TROOT, TListOfTypes, TBtree, TCollection, THashList, THashTable, TList, TObjArray, TListOfDataMembers, TListOfEnums, TListOfEnumsWithLock, TListOfFunctions, TListOfFunctionTemplates, TViewPubDataMembers, TViewPubFunctions, TPad, TGeometry, THbookFile, TGraph, TGraph2D, TH1, RooAbsCollection, and RooLinkedList.
Definition at line 435 of file TObject.cxx.
|
virtualinherited |
Get option used by the graphics system to draw this object.
Note that before calling object.GetDrawOption(), you must have called object.Draw(..) before in the current pad.
Reimplemented in TBrowser, TFitEditor, TGedFrame, TGFileBrowser, TRootBrowser, and TRootBrowserLite.
Definition at line 445 of file TObject.cxx.
|
staticinherited |
Return destructor only flag.
Definition at line 1196 of file TObject.cxx.
|
virtualinherited |
Returns mime type name of object.
Used by the TBrowser (via TGMimeTypes class). Override for class of which you would like to have different icons for objects of the same class.
Reimplemented in TSystemFile, TGeoVolume, TASImage, TGMainFrame, TKey, ROOT::Experimental::XRooFit::xRooNode, TBranch, TVirtualBranchBrowsable, TMethodBrowsable, and TBranchElement.
Definition at line 472 of file TObject.cxx.
| TLegend * TPie::GetLegend | ( | ) |
|
inlineoverridevirtualinherited |
Returns string containing info about the object at position (px,py).
This method is typically overridden by classes of which the objects can report peculiarities for different positions. Returned string will be re-used (lock in MT environment).
Reimplemented in TGeoNode, TGeoVolume, TGeoTrack, TASImage, TColorWheel, TAxis3D, TNode, TGL5DDataSet, TGLHistPainter, TGLParametricEquation, TGLTH3Composition, TF1, TF2, TGraph, TH1, THistPainter, TPaletteAxis, TFileDrawMap, TParallelCoordVar, and TVirtualHistPainter.
Definition at line 491 of file TObject.cxx.
|
staticinherited |
Get status of object stat flag.
Definition at line 1181 of file TObject.cxx.
Reimplemented in TGeoVolume, TArrow, TGaxis, TLegendEntry, TPave, TPolyLine, TAxis3D, THelix, TNode, TPolyLine3D, TPolyMarker3D, TH1, TPolyMarker, TFile, TMapFile, TPSocket, TSocket, TUDPSocket, TSelector, and TPoints3DABC.
Return the text alignment.
Reimplemented in TGWin32VirtualXProxy.
Definition at line 35 of file TAttText.h.
Return the text angle.
Reimplemented in TGWin32VirtualXProxy.
Definition at line 36 of file TAttText.h.
Return the text color.
Reimplemented in TGWin32VirtualXProxy.
Definition at line 37 of file TAttText.h.
Return the text font.
Reimplemented in TGWin32VirtualXProxy.
Definition at line 38 of file TAttText.h.
Return the text size.
Reimplemented in TGWin32VirtualXProxy.
Definition at line 39 of file TAttText.h.
Return the text in percent of the pad size.
Return the text size in percent of the pad size.
If the font precision is greater than 2, the text size returned is the size in pixel converted into percent of the pad size, otherwise the size returned is the same as the size given as input parameter.
Definition at line 316 of file TAttText.cxx.
|
virtualinherited |
Return the text size in pixels for specified pad.
Return the text size in pixels for the specified pad.
If the font precision less than 3 size defined as percent of pad size and scaled to minimal pad size
Definition at line 350 of file TAttText.cxx.
|
virtualinherited |
Return the text size in relative units.
If the font precision grater then 2 use pad dimensions to get value
Definition at line 333 of file TAttText.cxx.
|
inlineoverridevirtualinherited |
|
virtualinherited |
Return the unique object id.
Definition at line 480 of file TObject.cxx.
Execute action in response of a timer timing out.
This method must be overridden if an object has to react to timers.
Reimplemented in TGWindow, TGuiBldDragManager, TGraphTime, TGLEventHandler, TGCommandPlugin, TGDNDManager, TGFileContainer, TGPopupMenu, TGScrollBar, TGShutter, TGTextEdit, TGTextEditor, TGTextEntry, TGTextView, TGToolTip, TGHtml, and TTreeViewer.
Definition at line 516 of file TObject.cxx.
|
inlineoverridevirtualinherited |
Return hash value for this object.
Note: If this routine is overloaded in a derived class, this derived class should also add
Otherwise, when RecursiveRemove is called (by ~TObject or example) for this type of object, the transversal of THashList and THashTable containers will will have to be done without call Hash (and hence be linear rather than logarithmic complexity). You will also see warnings like
Reimplemented from TObject.
|
inlineinherited |
Return true is the type of this object is known to have an inconsistent setup for Hash and RecursiveRemove (i.e.
missing call to RecursiveRemove in destructor).
Note: Since the consistency is only tested for during inserts, this routine will return true for object that have never been inserted whether or not they have a consistent setup. This has no negative side-effect as searching for the object with the right or wrong Hash will always yield a not-found answer (Since anyway no hash can be guaranteed unique, there is always a check)
Issue info message.
Use "location" to specify the method where the warning occurred. Accepts standard printf formatting arguments.
Definition at line 1072 of file TObject.cxx.
Returns kTRUE if object inherits from class "classname".
Reimplemented in TClass.
Definition at line 549 of file TObject.cxx.
Returns kTRUE if object inherits from TClass cl.
Reimplemented in TClass.
Definition at line 557 of file TObject.cxx.
|
virtualinherited |
Dump contents of this object in a graphics canvas.
Same action as Dump but in a graphical form. In addition pointers to other objects can be followed.
The following picture is the Inspect of a histogram object:
Reimplemented in TSystemFile, TInspectorObject, TGFrame, and ROOT::Experimental::XRooFit::xRooNode.
Definition at line 570 of file TObject.cxx.
|
inlineoverridevirtual |
|
inlineinherited |
IsDestructed.
Default equal comparison (objects are equal if they have the same address in memory).
More complicated classes might want to override this function.
Reimplemented in TObjString, TQCommand, TPair, and TGObject.
Definition at line 589 of file TObject.cxx.
|
virtualinherited |
Returns kTRUE in case object contains browsable objects (like containers or lists of other objects).
Reimplemented in TDirectory, TFolder, TRemoteObject, TROOT, TSystemDirectory, TTask, TCollection, TPair, TBrowserObject, TBaseClass, TClass, TGeoManager, TGeoNode, TGeoNodeMatrix, TGeoVolume, TGeoOverlap, TGeoTrack, TCanvas, TPad, TAxis3D, TGeometry, TNode, TRootIconList, THbookFile, THbookKey, THnBase, ROOT::Internal::THnBaseBrowsable, TMultiDimFit, TPrincipal, TKey, TMapFile, TSPlot, TDatabasePDG, TParticleClassPDG, TApplicationRemote, ROOT::Experimental::XRooFit::xRooNode, TBranch, TVirtualBranchBrowsable, TBranchClones, TBranchElement, TBranchObject, TBranchSTL, and TTree.
Definition at line 579 of file TObject.cxx.
|
inlineinherited |
|
inlineoverridevirtualinherited |
Reimplemented from TObject.
Reimplemented in TStructNodeProperty.
|
inlineinherited |
|
overridevirtualinherited |
List TNamed name and title.
Reimplemented from TObject.
Reimplemented in ROOT::Experimental::XRooFit::xRooBrowser, TVirtualStreamerInfo, TROOT, TStreamerElement, TStreamerBase, TStreamerSTL, TText, TStreamerInfo, TTask, and TNode.
Definition at line 112 of file TNamed.cxx.
| TLegend * TPie::MakeLegend | ( | Double_t | x1 = .65, |
| Double_t | y1 = .65, | ||
| Double_t | x2 = .95, | ||
| Double_t | y2 = .95, | ||
| const char * | leg_header = "" ) |
This method create a legend that explains the contents of the slice for this pie-chart.
The parameter passed reppresents the option passed to shown the slices, see TLegend::AddEntry() for further details.
The pointer of the TLegend is returned.
|
inherited |
Use this method to signal that a method (defined in a base class) may not be called in a derived class (in principle against good design since a child class should not provide less functionality than its parent, however, sometimes it is necessary).
Definition at line 1160 of file TObject.cxx.
|
virtualinherited |
Change current text attributes if necessary.
Definition at line 364 of file TAttText.cxx.
|
virtualinherited |
Change current text attributes if necessary on specified pad.
Definition at line 373 of file TAttText.cxx.
|
virtualinherited |
This method must be overridden to handle object notification (the base implementation is no-op).
Different objects in ROOT use the Notify method for different purposes, in coordination with other objects that call this method at the appropriate time.
For example, TLeaf uses it to load class information; TBranchRef to load contents of referenced branches TBranchRef; most notably, based on Notify, TChain implements a callback mechanism to inform interested parties when it switches to a new sub-tree.
Reimplemented in TMessageHandler, TNotifyLink< Type >, TNotifyLink< RNoCleanupNotifierHelper >, TNotifyLink< ROOT::Detail::TBranchProxy >, TNotifyLink< TTreeReader >, TFileHandler, TSignalHandler, TStdExceptionHandler, TProcessEventTimer, TTimer, TIdleTimer, TSingleShotCleaner, TCollection, TRefTable, TBrowserTimer, TInterruptHandler, TTermInputHandler, TThreadTimer, TGLRedrawTimer, TViewTimer, TGContainerKeyboardTimer, TGContainerScrollTimer, TGInputHandler, TViewUpdateTimer, TPopupDelayTimer, TRepeatTimer, TSBRepeatTimer, TGTextEditHist, TInsCharCom, TDelCharCom, TBreakLineCom, TInsTextCom, TDelTextCom, TBlinkTimer, TTipDelayTimer, TGuiBldDragManagerRepeatTimer, TARInterruptHandler, TASLogHandler, TASInterruptHandler, TASSigPipeHandler, TASInputHandler, TSocketHandler, TTimeOutTimer, TBranchElement, TBranchRef, TLeafObject, TSelector, TTree, TSelectorDraw, TSelectorEntries, TTreeFormula, TTreeFormulaManager, TTreeReader, h1analysis, h1analysisTreeReader, and TSysEvtHandler.
Definition at line 618 of file TObject.cxx.
|
inherited |
Use this method to declare a method obsolete.
Specify as of which version the method is obsolete and as from which version it will be removed.
Definition at line 1169 of file TObject.cxx.
|
inherited |
Operator delete for sized deallocation.
Definition at line 1234 of file TObject.cxx.
|
inherited |
Operator delete.
Definition at line 1212 of file TObject.cxx.
|
inherited |
Only called by placement new when throwing an exception.
Definition at line 1266 of file TObject.cxx.
|
inherited |
Operator delete [] for sized deallocation.
Definition at line 1245 of file TObject.cxx.
|
inherited |
Operator delete [].
Definition at line 1223 of file TObject.cxx.
|
inherited |
Only called by placement new[] when throwing an exception.
Definition at line 1274 of file TObject.cxx.
|
inlineinherited |
|
inlineinherited |
|
inlineinherited |
|
overridevirtual |
Paint a Pie chart in a canvas.
See the class description for the possible drawing options
Reimplemented from TObject.
|
virtualinherited |
Pop on object drawn in a pad to the top of the display list.
I.e. it will be drawn last and on top of all other primitives.
Reimplemented in TPad, TFrame, and TVirtualPad.
Definition at line 640 of file TObject.cxx.
|
overridevirtualinherited |
Print TNamed name and title.
Reimplemented from TObject.
Reimplemented in TSQLFile, TXMLFile, TScatter, TScatter2D, TParticleClassPDG, TParticlePDG, ROOT::Experimental::XRooFit::xRooNLLVar::xRooHypoPoint, ROOT::Experimental::XRooFit::xRooNLLVar::xRooHypoSpace, ROOT::Experimental::XRooFit::xRooNode, TPrincipal, TText, TXTRU, TSpectrum, TSpectrum2, TSpectrum3, TSQLColumnInfo, TSQLTableInfo, TTree, TTreeIndex, TParallelCoordVar, and TParallelCoordRange.
Definition at line 127 of file TNamed.cxx.
Read contents of object with specified name from the current directory.
First the key with the given name is searched in the current directory, next the key buffer is deserialized into the object. The object must have been created before via the default constructor. See TObject::Write().
Reimplemented in TKeyXML, TBuffer, TKey, and TKeySQL.
Definition at line 673 of file TObject.cxx.
|
virtualinherited |
Recursively remove this object from a list.
Typically implemented by classes that can contain multiple references to a same object.
Reimplemented in THistPainter, TCling, TDirectory, TFolder, TProcessID, TROOT, TCollection, THashList, TList, TObjArray, TBrowser, TObjectSpy, TObjectRefSpy, TListOfDataMembers, TListOfEnums, TListOfEnumsWithLock, TListOfFunctions, TListOfFunctionTemplates, ROOT::Internal::TCheckHashRecursiveRemoveConsistency, TViewPubDataMembers, TViewPubFunctions, TDialogCanvas, TInspectCanvas, TPad, TLegend, TGeometry, TNode, ROOT::RBrowserDataCleanup, TFitEditor, TGedEditor, TH1Editor, TH2Editor, TGFileBrowser, TRootBrowser, TRootBrowserLite, TRootContextMenu, TRootBrowserHistory, TEfficiency, TGraph, TGraph2D, TH1, THStack, TMultiGraph, TFileMerger, RooAbsCollection, RooAbsData, RooLinkedList, RooMCStudy, RooWorkspace, TChain, TFriendElement, TTree, TTreePlayer, and TVirtualPad.
Definition at line 684 of file TObject.cxx.
|
virtualinherited |
Reset this text attributes to default values.
Reimplemented in TGWin32VirtualXProxy.
Definition at line 387 of file TAttText.cxx.
Save this object in the file specified by filename.
otherwise the object is written to filename as a CINT/C++ script. The C++ code to rebuild this object is generated via SavePrimitive(). The "option" parameter is passed to SavePrimitive. By default it is an empty string. It can be used to specify the Draw option in the code generated by SavePrimitive.
The function is available via the object context menu.
Reimplemented in TSpline, TFolder, TGeoVolume, TClassTree, TPad, TPaveClass, TGObject, TSpline3, TSpline5, ROOT::Experimental::XRooFit::xRooNode, TTreePerfStats, TVirtualPad, TGraph, and TH1.
Definition at line 708 of file TObject.cxx.
|
overridevirtual |
Save primitive as a C++ statement(s) on output stream out.
Reimplemented from TObject.
|
staticprotectedinherited |
Save object constructor in the output stream "out".
Can be used as first statement when implementing SavePrimitive() method for the object
Definition at line 777 of file TObject.cxx.
|
staticprotectedinherited |
Save invocation of primitive Draw() method Skipped if option contains "nodraw" string.
Definition at line 845 of file TObject.cxx.
|
protectedinherited |
Save object name and title into the output stream "out".
Definition at line 135 of file TNamed.cxx.
|
staticprotectedinherited |
Save array in the output stream "out" as vector.
Create unique variable name based on prefix value Returns name of vector which can be used in constructor or in other places of C++ code If flag === kTRUE, just add empty line If flag === 111, check if array is empty and return nullptr or <vectorname>.data()
Definition at line 796 of file TObject.cxx.
|
virtualinherited |
Save text attributes as C++ statement(s) on output stream out.
Definition at line 399 of file TAttText.cxx.
| void TPie::SetAngle3D | ( | Float_t | val = 30. | ) |
| void TPie::SetAngularOffset | ( | Double_t | offset | ) |
Set or unset the user status bits as specified in f.
Definition at line 888 of file TObject.cxx.
|
virtualinherited |
Set drawing option for object.
This option only affects the drawing style and is stored in the option field of the TObjOptLink supporting a TPad's primitive list (TList). Note that it does not make sense to call object.SetDrawOption(option) before having called object.Draw().
Reimplemented in TSystemDirectory, TSystemFile, TPad, TGFrame, TAxis, TBrowser, TPaveStats, TGedFrame, TRootBrowserLite, and RooPlot.
Definition at line 871 of file TObject.cxx.
|
staticinherited |
Set destructor only flag.
Definition at line 1204 of file TObject.cxx.
| void TPie::SetFillColors | ( | Int_t * | colors | ) |
| void TPie::SetFractionFormat | ( | const char * | fmt | ) |
Set numeric format in the label, is used if the label format there is the modifier frac, in this case the value is printed using this format.
The numeric format use the standard C modifier used in stdio library: f, %2.1$, e... for further documentation you can use the printf man page ("man 3 printf" on linux)
Example:
| void TPie::SetHeight | ( | Double_t | val = .08 | ) |
| void TPie::SetLabelFormat | ( | const char * | fmt | ) |
This method is used to customize the label format.
| void TPie::SetLabels | ( | const char * | lbls[] | ) |
| void TPie::SetLabelsOffset | ( | Float_t | labelsoffset | ) |
|
virtualinherited |
Set the name of the TNamed.
WARNING: if the object is a member of a THashTable or THashList container the container must be Rehash()'ed after SetName(). For example the list of objects in the current directory is a THashList.
Reimplemented in TEveScene, TColor, TSystemDirectory, TSystemFile, TNode, TRotMatrix, TShape, TEfficiency, TFormula, TGraph2D, TH1, RooAbsArg, RooAbsData, RooDataHist, RooDataSet, RooFitResult, RooPlot, ROOT::Experimental::XRooFit::xRooNode, TChain, TEventList, TTree, TGraph, and TDirectory.
Definition at line 149 of file TNamed.cxx.
Set all the TNamed parameters (name and title).
WARNING: if the name is changed and the object is a member of a THashTable or THashList container the container must be Rehash()'ed after SetName(). For example the list of objects in the current directory is a THashList.
Reimplemented in TContextMenu, TNode, TGraph2D, TH1, RooAbsArg, RooAbsData, RooDataHist, RooDataSet, RooFitResult, RooPlot, and TGraph.
Definition at line 163 of file TNamed.cxx.
|
staticinherited |
Turn on/off tracking of objects in the TObjectTable.
Definition at line 1188 of file TObject.cxx.
| void TPie::SetPercentFormat | ( | const char * | fmt | ) |
| void TPie::SetRadius | ( | Double_t | rad | ) |
Set the text alignment.
Reimplemented in TVirtualX, TGQuartz, TGWin32, TGWin32VirtualXProxy, and TGX11.
Definition at line 48 of file TAttText.h.
Set the text angle.
Reimplemented in TGWin32VirtualXProxy, and TGraphNode.
Definition at line 49 of file TAttText.h.
|
virtualinherited |
Invoke the DialogCanvas Text attributes.
Reimplemented in TGWin32VirtualXProxy.
Definition at line 418 of file TAttText.cxx.
Set the text color.
Reimplemented in TVirtualX, TGQuartz, TGWin32, TGX11, TPDF, TPostScript, TSVG, TTeXDump, and TGWin32VirtualXProxy.
Definition at line 50 of file TAttText.h.
|
inherited |
Definition at line 453 of file TAttText.cxx.
Set a transparent text color.
| tcolor | defines the text color |
| talpha | defines the percentage of opacity from 0. (fully transparent) to 1. (fully opaque). |
Definition at line 430 of file TAttText.cxx.
Set the text font.
Reimplemented in TVirtualX, TGQuartz, TGWin32, TGX11, and TGWin32VirtualXProxy.
Definition at line 52 of file TAttText.h.
Set the text size.
Reimplemented in TVirtualX, TGQuartz, TGWin32, TGX11, and TGWin32VirtualXProxy.
Definition at line 53 of file TAttText.h.
|
virtualinherited |
Set the text size in pixel.
Set the text size in pixels.
If the font precision is greater than 2, the text size is set to npixels, otherwise the text size is computed as a percent of the pad size.
Reimplemented in TGWin32VirtualXProxy.
Definition at line 441 of file TAttText.cxx.
|
virtualinherited |
Set the title of the TNamed.
Reimplemented in ROOT::TSchemaRule::TSources, TParallelCoordVar, RooPlot, TSystemDirectory, TSystemFile, TEfficiency, TH1, THnBase, ROOT::Experimental::XRooFit::xRooNode, Axis2, TASImage, TF1, TGraph, and TGraph2D.
Definition at line 173 of file TNamed.cxx.
|
virtualinherited |
Set the unique object id.
Definition at line 899 of file TObject.cxx.
| void TPie::SetValueFormat | ( | const char * | fmt | ) |
Set the numeric format the slices' values.
Used by val (see SetLabelFormat()).
|
virtualinherited |
Return size of the TNamed part of the TObject.
Reimplemented in TSQLFile, TXMLFile, TDirectory, TDirectoryFile, TFile, and TKey.
Definition at line 182 of file TNamed.cxx.
This method, mainly intended for internal use, ordered the slices according their values.
The default (amode=kTRUE) is increasing order, but is also possible in decreasing order (amode=kFALSE).
If the merge_threshold>0 the slice that contains a quantity smaller than merge_threshold are merged together
|
overridevirtual |
|
inline |
Issue system error message.
Use "location" to specify the method where the system error occurred. Accepts standard printf formatting arguments.
Definition at line 1112 of file TObject.cxx.
|
inlineinherited |
|
virtualinherited |
Set current style settings in this object This function is called when either TCanvas::UseCurrentStyle or TROOT::ForceStyle have been invoked.
Reimplemented in TCanvas, TPad, TFrame, TPaveStats, TPaveText, TAxis3D, TGraph, TH1, and TTree.
Definition at line 909 of file TObject.cxx.
Issue warning message.
Use "location" to specify the method where the warning occurred. Accepts standard printf formatting arguments.
Definition at line 1084 of file TObject.cxx.
|
virtualinherited |
Write this object to the current directory.
For more see the const version of this method.
Reimplemented in TSQLFile, TXMLFile, TDirectory, TBuffer, ROOT::TBufferMergerFile, TDirectoryFile, TFile, TParallelMergingFile, TCollection, TMap, and TTree.
Definition at line 989 of file TObject.cxx.
|
virtualinherited |
Write this object to the current directory.
The data structure corresponding to this object is serialized. The corresponding buffer is written to the current directory with an associated key with name "name".
Writing an object to a file involves the following steps:
Bufsize can be given to force a given buffer size to write this object. By default, the buffersize will be taken from the average buffer size of all objects written to the current file so far.
If a name is specified, it will be the name of the key. If name is not given, the name of the key will be the name as returned by GetName().
The option can be a combination of: kSingleKey, kOverwrite or kWriteDelete Using the kOverwrite option a previous key with the same name is overwritten. The previous key is deleted before writing the new object. Using the kWriteDelete option a previous key with the same name is deleted only after the new object has been written. This option is safer than kOverwrite but it is slower. NOTE: Neither kOverwrite nor kWriteDelete reduces the size of a TFile– the space is simply freed up to be overwritten; in the case of a TTree, it is more complicated. If one opens a TTree, appends some entries, then writes it out, the behaviour is effectively the same. If, however, one creates a new TTree and writes it out in this way, only the metadata is replaced, effectively making the old data invisible without deleting it. TTree::Delete() can be used to mark all disk space occupied by a TTree as free before overwriting its metadata this way. The kSingleKey option is only used by TCollection::Write() to write a container with a single key instead of each object in the container with its own key.
An object is read from the file into memory via TKey::Read() or via TObject::Read().
The function returns the total number of bytes written to the file. It returns 0 if the object cannot be written.
Reimplemented in TSQLFile, TXMLFile, TDirectory, TBuffer, TDirectoryFile, TFile, TParallelMergingFile, TCollection, TMap, and TTree.
Definition at line 964 of file TObject.cxx.
|
protected |
|
protected |
|
privateinherited |
|
protected |
|
staticprivateinherited |
if true keep track of objects in TObjectTable
|
protected |
|
protected |
|
protected |
|
protected |
|
private |
|
protected |
|
protected |
|
private |
|
protectedinherited |
Text alignment.
Definition at line 26 of file TAttText.h.
|
protectedinherited |
Text angle.
Definition at line 24 of file TAttText.h.
|
protectedinherited |
Text color.
Definition at line 27 of file TAttText.h.
|
protectedinherited |
Text font.
Definition at line 28 of file TAttText.h.
|
protectedinherited |
Text size.
Definition at line 25 of file TAttText.h.
|
privateinherited |
|
protected |
