To draw Mathematical Formula.

TLatex's purpose is to write mathematical equations. The syntax is very similar to the Latex's one. It provides several functionalities:

When the font precision (see TAttText) is low (0 or 1), TLatex is painted as a normal TText, the control characters are not interpreted.

Subscripts and Superscripts

Subscripts and superscripts are made with the _ and ^ commands. These commands can be combined to make complicated subscript and superscript expressions. You may adjust the display of subscripts and superscripts by using the two functions SetIndiceSize(Double_t), which set relative size of subscripts and superscripts, and SetLimitIndiceSize(Int_t), which set limits for text resizing of subscripts and superscripts.

Examples:

The best way to put the subscripts and superscripts before the character and not after, is to use an empty character:

The subscripts and superscripts operators apply not only on one character but on all the "normal text" preceding them. In the following example the second E is lower than the first one because the operator _ is applied on /f which has a descending part, and not only on f which as no descending part.

To make sure the second operator _ applies only on f a dummy operator ^{} should be introduced to separate the f from the /.

Fractions

Fractions denoted by the / symbol are made in the obvious way. The #frac command is used for large fractions in displayed formula; it has two arguments: the numerator and the denominator.

Examples:

Splitting Lines

Text can be split in two lines via the command #splitline.

Examples:

Roots

The #sqrt command produces the square root of its argument; it has an optional first argument for other roots.

Examples:

Mathematical Symbols

TLatex can display dozens of special mathematical symbols. A few of them, such as + and > , are produced by typing the corresponding keyboard character. Others are obtained with the commands in the following table:

Delimiters

TLatex provides 4 kinds of proportional delimiters:

#[]{....} or "a la" Latex #left[.....#right] : big square brackets
#{}{....} or              #left{.....#right} : big curly brackets
#||{....} or              #left|.....#right| : big absolute value symbols
#(){....} or              #left(.....#right) : big parentheses

Greek Letters

The command to produce a lowercase Greek letter is obtained by adding a # to the name of the letter. For an uppercase Greek letter, just capitalize the first letter of the command name. Some letters have two representations. The name of the second one (the "variation") starts with "var". The following table gives the complete list:

Accents

Several kind of accents are available:

The special sign: #slash draws a slash on top of the text between brackets:

Bar and vectors sign are done the following way:

Changing Style

One can change the font, the text color, or the text size at any time using : #font[font-number]{...}, #color[color-number]{...} and #scale[scale-factor]{...}

Examples:

Alignment Rules

The TText alignment rules apply to the TLatex objects with one exception concerning the vertical alignment:

if the vertical alignment = 1 , subscripts are not taken into account
if the vertical alignment = 0 , the text is aligned to the box surrounding the full text with sub and superscripts

This is illustrated by the following example:

{
   TCanvas Tlva("Tlva","Tlva",500,500);
   Tlva.SetGrid();
   Tlva.DrawFrame(0,0,1,1);
   const char *longstring = "K_{S}... K^{*0}... #frac{2s}{#pi#alpha^{2}} #frac{d#sigma}{dcos#theta} (e^{+}e^{-} #rightarrow f#bar{f} ) = #left| #frac{1}{1 - #Delta#alpha} #right|^{2} (1+cos^{2}#theta)";

   TLatex latex;
   latex.SetTextSize(0.025);
   latex.SetTextAlign(13);  //align at top
   latex.DrawLatex(.2,.9,"K_{S}");
   latex.DrawLatex(.3,.9,"K^{*0}");
   latex.DrawLatex(.2,.8,longstring);

   latex.SetTextAlign(12);  //centered
   latex.DrawLatex(.2,.6,"K_{S}");
   latex.DrawLatex(.3,.6,"K^{*0}");
   latex.DrawLatex(.2,.5,longstring);

   latex.SetTextAlign(11);  //default bottom alignment
   latex.DrawLatex(.2,.4,"K_{S}");
   latex.DrawLatex(.3,.4,"K^{*0}");
   latex.DrawLatex(.2,.3,longstring);

   latex.SetTextAlign(10);  //special bottom alignment
   latex.DrawLatex(.2,.2,"K_{S}");
   latex.DrawLatex(.3,.2,"K^{*0}");
   latex.DrawLatex(.2,.1,longstring);

   latex.SetTextAlign(12);
   latex.SetTextFont(72);
   latex.DrawLatex(.1,.80,"13");
   latex.DrawLatex(.1,.55,"12");
   latex.DrawLatex(.1,.35,"11");
   latex.DrawLatex(.1,.18,"10");
   return Tlva;
}

Character Adjustment

The two commands #kern and #lower enable a better control over character placement. The command #kern[(Float_t)dx]{text} moves the output string horizontally by the fraction dx of its length. Similarly, #lower[(Float_t)dy]{text} shifts the text up or down by the fraction dy of its height.

Examples:

Italic and Boldface

Text can be turned italic or boldface using the commands #it and #bf.

Examples:

Examples

{
   TCanvas ex1("ex1","Latex",500,600);
   TLatex Tl;
   Tl.SetTextAlign(12);
   Tl.SetTextSize(0.04);
   Tl.DrawLatex(0.1,0.8,"1)   C(x) = d #sqrt{#frac{2}{#lambdaD}}  #int^{x}_{0}cos(#frac{#pi}{2}t^{2})dt");
   Tl.DrawLatex(0.1,0.6,"2)   C(x) = d #sqrt{#frac{2}{#lambdaD}}  #int^{x}cos(#frac{#pi}{2}t^{2})dt");
   Tl.DrawLatex(0.1,0.4,"3)   R = |A|^{2} = #frac{1}{2}(#[]{#frac{1}{2}+C(V)}^{2}+#[]{#frac{1}{2}+S(V)}^{2})");
   Tl.DrawLatex(0.1,0.2,"4)   F(t) = #sum_{i=-#infty}^{#infty}A(i)cos#[]{#frac{i}{t+i}}");
   return ex1;
}

{
   TCanvas ex2("ex2","Latex",500,300);
   TLatex Tl;
   Tl.SetTextAlign(23);
   Tl.SetTextSize(0.08);
   Tl.DrawLatex(0.5,0.95,"e^{+}e^{-}#rightarrowZ^{0}#rightarrowI#bar{I}, q#bar{q}");
   Tl.DrawLatex(0.5,0.75,"|#vec{a}#bullet#vec{b}|=#Sigmaa^{i}_{jk}+b^{bj}_{i}");
   Tl.DrawLatex(0.5,0.5,"i(#partial_{#mu}#bar{#psi}#gamma^{#mu}+m#bar{#psi}=0#Leftrightarrow(#Box+m^{2})#psi=0");
   Tl.DrawLatex(0.5,0.3,"L_{em}=eJ^{#mu}_{em}A_{#mu} , J^{#mu}_{em}=#bar{I}#gamma_{#mu}I , M^{j}_{i}=#SigmaA_{#alpha}#tau^{#alphaj}_{i}");
   return ex2;
}

{
   TCanvas ex3("ex3","Latex",500,300);
   TPaveText pt(.1,.1,.9,.9);
   pt.AddText("#frac{2s}{#pi#alpha^{2}}  #frac{d#sigma}{dcos#theta} (e^{+}e^{-} #rightarrow f#bar{f} ) = ");
   pt.AddText("#left| #frac{1}{1 - #Delta#alpha} #right|^{2} (1+cos^{2}#theta");
   pt.AddText("+ 4 Re #left{ #frac{2}{1 - #Delta#alpha} #chi(s) #[]{#hat{g}_{#nu}^{e}#hat{g}_{#nu}^{f} (1 + cos^{2}#theta) + 2 #hat{g}_{a}^{e}#hat{g}_{a}^{f} cos#theta) } #right}");
   pt.SetLabel("Born equation");
   pt.Draw();
   return ex3;
}

Interface to TMathText

The class TMathText is a TeX math formulae interpreter. It uses plain TeX syntax and uses "\\" as control instead of "#". If a piece of text containing "\" is given to TLatex then TMathText is automatically invoked. Therefore, as histograms' titles, axis titles, labels etc ... are drawn using TLatex, the TMathText syntax can be used for them also.

Definition at line 18 of file TLatex.h.

Classes
struct	TextSpec_t
	TLatex helper struct holding the attributes of a piece of text. More...

class	TLatexFormSize
	TLatex helper class used to compute the size of a portion of a formula. More...

Public Types
enum	{ kTextNDC = (1ULL << ( 14 )) }

Public Types inherited from TText
enum	{ kTextNDC = (1ULL << ( 14 )) }

Public Types inherited from TObject
enum	{ kIsOnHeap = 0x01000000 , kNotDeleted = 0x02000000 , kZombie = 0x04000000 , kInconsistent = 0x08000000 , kBitMask = 0x00ffffff }

enum	{ kSingleKey = (1ULL << ( 0 )) , kOverwrite = (1ULL << ( 1 )) , kWriteDelete = (1ULL << ( 2 )) }

enum	EDeprecatedStatusBits { kObjInCanvas = (1ULL << ( 3 )) }

enum	EStatusBits { kCanDelete = (1ULL << ( 0 )) , kMustCleanup = (1ULL << ( 3 )) , kIsReferenced = (1ULL << ( 4 )) , kHasUUID = (1ULL << ( 5 )) , kCannotPick = (1ULL << ( 6 )) , kNoContextMenu = (1ULL << ( 8 )) , kInvalidObject = (1ULL << ( 13 )) }

Public Member Functions
	TLatex ()
	Default constructor.

	TLatex (const TLatex &text)
	Copy constructor.

	TLatex (Double_t x, Double_t y, const char *text)
	Normal constructor.

	~TLatex () override
	Destructor.

void	Copy (TObject &text) const override
	Copy this TLatex object to another TLatex.

TLatex *	DrawLatex (Double_t x, Double_t y, const char *text)
	Make a copy of this object with the new parameters And copy object attributes.

TLatex *	DrawLatexNDC (Double_t x, Double_t y, const char *text)
	Draw this TLatex with new coordinates in NDC.

void	GetBoundingBox (UInt_t &w, UInt_t &h, Bool_t angle=kFALSE) override
	Return text size in pixels.

Double_t	GetHeight () const
	Return height of current pad in pixels.

Double_t	GetXsize ()
	Return size of the formula along X in pad coordinates when the text precision is smaller than 3.

Double_t	GetYsize ()
	Return size of the formula along Y in pad coordinates when the text precision is smaller than 3.

TClass *	IsA () const override

void	Paint (Option_t *option="") override
	Paint.

virtual void	PaintLatex (Double_t x, Double_t y, Double_t angle, Double_t size, const char *text)
	Main drawing function.

void	SavePrimitive (std::ostream &out, Option_t *option="") override
	Save primitive as a C++ statement(s) on output stream out.

virtual void	SetIndiceSize (Double_t factorSize)
	Set relative size of subscripts and superscripts.

virtual void	SetLimitIndiceSize (Int_t limitFactorSize)
	Set limit for text resizing of subscripts and superscripts.

void	Streamer (TBuffer &) override
	Stream an object of class TObject.

void	StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

Public Member Functions inherited from TText
	TText ()

	TText (const TText &text)
	Copy constructor.

	TText (Double_t x, Double_t y, const char *text)
	Text normal constructor.

	TText (Double_t x, Double_t y, const wchar_t *text)
	Text normal constructor.

	~TText () override
	Text default destructor.

void	Copy (TObject &text) const override
	Copy this text to text.

Int_t	DistancetoPrimitive (Int_t px, Int_t py) override
	Compute distance from point px,py to a string.

virtual TText *	DrawText (Double_t x, Double_t y, const char *text)
	Draw this text with new coordinates.

virtual TText *	DrawText (Double_t x, Double_t y, const wchar_t *text)
	Draw this text with new coordinates.

virtual TText *	DrawTextNDC (Double_t x, Double_t y, const char *text)
	Draw this text with new coordinates in NDC.

virtual TText *	DrawTextNDC (Double_t x, Double_t y, const wchar_t *text)
	Draw this text with new coordinates in NDC.

void	ExecuteEvent (Int_t event, Int_t px, Int_t py) override
	Execute action corresponding to one event.

Rectangle_t	GetBBox () override
	Return the "bounding Box" of the Box.

TPoint	GetBBoxCenter () override
	Return the point given by Alignment as 'center'.

virtual void	GetControlBox (Int_t x, Int_t y, Double_t theta, Int_t cBoxX[4], Int_t cBoxY[4])
	Return the text control box.

virtual void	GetTextAdvance (UInt_t &a, const char *text, const Bool_t kern=kTRUE) const
	Return text advance for string text if kern is true (default) kerning is taken into account.

virtual void	GetTextAscentDescent (UInt_t &a, UInt_t &d, const char *text) const
	Return text ascent and descent for string text.

virtual void	GetTextAscentDescent (UInt_t &a, UInt_t &d, const wchar_t *text) const
	Return text ascent and descent for string text.

virtual void	GetTextExtent (UInt_t &w, UInt_t &h, const char *text) const
	Return text extent for string text.

virtual void	GetTextExtent (UInt_t &w, UInt_t &h, const wchar_t *text) const
	Return text extent for string text.

const void *	GetWcsTitle (void) const
	Returns the text as UNICODE.

Double_t	GetX () const

Double_t	GetY () const

TClass *	IsA () const override

void	ls (Option_t *option="") const override
	List this text with its attributes.

TText &	operator= (const TText &src)
	Assignment operator.

void	Paint (Option_t *option="") override
	Paint this text with its current attributes.

virtual void	PaintControlBox (Int_t x, Int_t y, Double_t theta)
	Paint the text control box.

virtual void	PaintText (Double_t x, Double_t y, const char *text)
	Draw this text with new coordinates.

virtual void	PaintText (Double_t x, Double_t y, const wchar_t *text)
	Draw this text with new coordinates.

virtual void	PaintTextNDC (Double_t u, Double_t v, const char *text)
	Draw this text with new coordinates in NDC.

virtual void	PaintTextNDC (Double_t u, Double_t v, const wchar_t *text)
	Draw this text with new coordinates in NDC.

void	Print (Option_t *option="") const override
	Dump this text with its attributes.

void	SavePrimitive (std::ostream &out, Option_t *option="") override
	Save primitive as a C++ statement(s) on output stream out.

void	SetBBoxCenter (const TPoint &p) override
	Set the point given by Alignment as 'center'.

void	SetBBoxCenterX (const Int_t x) override
	Set X coordinate of the point given by Alignment as 'center'.

void	SetBBoxCenterY (const Int_t y) override
	Set Y coordinate of the point given by Alignment as 'center'.

void	SetBBoxX1 (const Int_t) override
	Set left hand side of BoundingBox to a value (resize in x direction on left)

void	SetBBoxX2 (const Int_t) override
	Set right hand side of BoundingBox to a value (resize in x direction on right)

void	SetBBoxY1 (const Int_t) override
	Set top of BoundingBox to a value (resize in y direction on top)

void	SetBBoxY2 (const Int_t) override
	Set bottom of BoundingBox to a value (resize in y direction on bottom)

virtual void	SetMbTitle (const wchar_t *title=L"")
	Change (i.e. set) the title of the TNamed.

virtual void	SetNDC (Bool_t isNDC=kTRUE)
	Set NDC mode on if isNDC = kTRUE, off otherwise.

virtual void	SetText (Double_t x, Double_t y, const char *text)

virtual void	SetText (Double_t x, Double_t y, const wchar_t *text)

virtual void	SetX (Double_t x)

virtual void	SetY (Double_t y)

void	Streamer (TBuffer &) override
	Stream an object of class TText.

void	StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

Public Member Functions inherited from TNamed
	TNamed ()

	TNamed (const char name, const char title)

	TNamed (const TNamed &named)
	TNamed copy ctor.

	TNamed (const TString &name, const TString &title)

virtual	~TNamed ()
	TNamed destructor.

void	Clear (Option_t *option="") override
	Set name and title to empty strings ("").

TObject *	Clone (const char *newname="") const override
	Make a clone of an object using the Streamer facility.

Int_t	Compare (const TObject *obj) const override
	Compare two TNamed objects.

virtual void	FillBuffer (char *&buffer)
	Encode TNamed into output buffer.

const char *	GetName () const override
	Returns name of object.

const char *	GetTitle () const override
	Returns title of object.

ULong_t	Hash () const override
	Return hash value for this object.

Bool_t	IsSortable () const override

TNamed &	operator= (const TNamed &rhs)
	TNamed assignment operator.

virtual void	SetName (const char *name)
	Set the name of the TNamed.

virtual void	SetNameTitle (const char name, const char title)
	Set all the TNamed parameters (name and title).

virtual void	SetTitle (const char *title="")
	Set the title of the TNamed.

virtual Int_t	Sizeof () const
	Return size of the TNamed part of the TObject.

void	StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

Public Member Functions inherited from TObject
	TObject ()
	TObject constructor.

	TObject (const TObject &object)
	TObject copy ctor.

virtual	~TObject ()
	TObject destructor.

void	AbstractMethod (const char *method) const
	Use this method to implement an "abstract" method that you don't want to leave purely abstract.

virtual void	AppendPad (Option_t *option="")
	Append graphics object to current pad.

virtual void	Browse (TBrowser *b)
	Browse object. May be overridden for another default action.

ULong_t	CheckedHash ()
	Check and record whether this class has a consistent Hash/RecursiveRemove setup (*) and then return the regular Hash value for this object.

virtual const char *	ClassName () const
	Returns name of class to which the object belongs.

virtual void	Delete (Option_t *option="")
	Delete this object.

virtual void	Draw (Option_t *option="")
	Default Draw method for all objects.

virtual void	DrawClass () const
	Draw class inheritance tree of the class to which this object belongs.

virtual TObject *	DrawClone (Option_t *option="") const
	Draw a clone of this object in the current selected pad with: `gROOT->SetSelectedPad(c1)`.

virtual void	Dump () const
	Dump contents of object on stdout.

virtual void	Error (const char method, const char msgfmt,...) const
	Issue error message.

virtual void	Execute (const char method, const char params, Int_t *error=nullptr)
	Execute method on this object with the given parameter string, e.g.

virtual void	Execute (TMethod method, TObjArray params, Int_t *error=nullptr)
	Execute method on this object with parameters stored in the TObjArray.

virtual void	Fatal (const char method, const char msgfmt,...) const
	Issue fatal error message.

virtual TObject *	FindObject (const char *name) const
	Must be redefined in derived classes.

virtual TObject *	FindObject (const TObject *obj) const
	Must be redefined in derived classes.

virtual Option_t *	GetDrawOption () const
	Get option used by the graphics system to draw this object.

virtual const char *	GetIconName () const
	Returns mime type name of object.

virtual char *	GetObjectInfo (Int_t px, Int_t py) const
	Returns string containing info about the object at position (px,py).

virtual Option_t *	GetOption () const

virtual UInt_t	GetUniqueID () const
	Return the unique object id.

virtual Bool_t	HandleTimer (TTimer *timer)
	Execute action in response of a timer timing out.

Bool_t	HasInconsistentHash () const
	Return true is the type of this object is known to have an inconsistent setup for Hash and RecursiveRemove (i.e.

virtual void	Info (const char method, const char msgfmt,...) const
	Issue info message.

virtual Bool_t	InheritsFrom (const char *classname) const
	Returns kTRUE if object inherits from class "classname".

virtual Bool_t	InheritsFrom (const TClass *cl) const
	Returns kTRUE if object inherits from TClass cl.

virtual void	Inspect () const
	Dump contents of this object in a graphics canvas.

void	InvertBit (UInt_t f)

Bool_t	IsDestructed () const
	IsDestructed.

virtual Bool_t	IsEqual (const TObject *obj) const
	Default equal comparison (objects are equal if they have the same address in memory).

virtual Bool_t	IsFolder () const
	Returns kTRUE in case object contains browsable objects (like containers or lists of other objects).

R__ALWAYS_INLINE Bool_t	IsOnHeap () const

R__ALWAYS_INLINE Bool_t	IsZombie () const

void	MayNotUse (const char *method) const
	Use this method to signal that a method (defined in a base class) may not be called in a derived class (in principle against good design since a child class should not provide less functionality than its parent, however, sometimes it is necessary).

virtual Bool_t	Notify ()
	This method must be overridden to handle object notification (the base implementation is no-op).

void	Obsolete (const char method, const char asOfVers, const char *removedFromVers) const
	Use this method to declare a method obsolete.

void	operator delete (void *ptr)
	Operator delete.

void	operator delete (void ptr, void vp)
	Only called by placement new when throwing an exception.

void	operator delete[] (void *ptr)
	Operator delete [].

void	operator delete[] (void ptr, void vp)
	Only called by placement new[] when throwing an exception.

void *	operator new (size_t sz)

void *	operator new (size_t sz, void *vp)

void *	operator new[] (size_t sz)

void *	operator new[] (size_t sz, void *vp)

TObject &	operator= (const TObject &rhs)
	TObject assignment operator.

virtual void	Pop ()
	Pop on object drawn in a pad to the top of the display list.

virtual Int_t	Read (const char *name)
	Read contents of object with specified name from the current directory.

virtual void	RecursiveRemove (TObject *obj)
	Recursively remove this object from a list.

void	ResetBit (UInt_t f)

virtual void	SaveAs (const char filename="", Option_t option="") const
	Save this object in the file specified by filename.

void	SetBit (UInt_t f)

void	SetBit (UInt_t f, Bool_t set)
	Set or unset the user status bits as specified in f.

virtual void	SetDrawOption (Option_t *option="")
	Set drawing option for object.

virtual void	SetUniqueID (UInt_t uid)
	Set the unique object id.

void	StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

virtual void	SysError (const char method, const char msgfmt,...) const
	Issue system error message.

R__ALWAYS_INLINE Bool_t	TestBit (UInt_t f) const

Int_t	TestBits (UInt_t f) const

virtual void	UseCurrentStyle ()
	Set current style settings in this object This function is called when either TCanvas::UseCurrentStyle or TROOT::ForceStyle have been invoked.

virtual void	Warning (const char method, const char msgfmt,...) const
	Issue warning message.

virtual Int_t	Write (const char *name=nullptr, Int_t option=0, Int_t bufsize=0)
	Write this object to the current directory.

virtual Int_t	Write (const char *name=nullptr, Int_t option=0, Int_t bufsize=0) const
	Write this object to the current directory.

Public Member Functions inherited from TAttText
	TAttText ()
	AttText default constructor.

	TAttText (Int_t align, Float_t angle, Color_t color, Style_t font, Float_t tsize)
	AttText normal constructor.

virtual	~TAttText ()
	AttText destructor.

void	Copy (TAttText &atttext) const
	Copy this text attributes to a new TAttText.

virtual Short_t	GetTextAlign () const
	Return the text alignment.

virtual Float_t	GetTextAngle () const
	Return the text angle.

virtual Color_t	GetTextColor () const
	Return the text color.

virtual Font_t	GetTextFont () const
	Return the text font.

virtual Float_t	GetTextSize () const
	Return the text size.

virtual Float_t	GetTextSizePercent (Float_t size)
	Return the text in percent of the pad size.

virtual void	Modify ()
	Change current text attributes if necessary.

virtual void	ResetAttText (Option_t *toption="")
	Reset this text attributes to default values.

virtual void	SaveTextAttributes (std::ostream &out, const char *name, Int_t alidef=12, Float_t angdef=0, Int_t coldef=1, Int_t fondef=61, Float_t sizdef=1)
	Save text attributes as C++ statement(s) on output stream out.

virtual void	SetTextAlign (Short_t align=11)
	Set the text alignment.

virtual void	SetTextAngle (Float_t tangle=0)
	Set the text angle.

virtual void	SetTextAttributes ()
	Invoke the DialogCanvas Text attributes.

virtual void	SetTextColor (Color_t tcolor=1)
	Set the text color.

virtual void	SetTextColorAlpha (Color_t tcolor, Float_t talpha)
	Set a transparent text color.

virtual void	SetTextFont (Font_t tfont=62)
	Set the text font.

virtual void	SetTextSize (Float_t tsize=1)
	Set the text size.

virtual void	SetTextSizePixels (Int_t npixels)
	Set the text size in pixel.

void	StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

Public Member Functions inherited from TAttBBox2D
virtual	~TAttBBox2D ()

void	StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

Public Member Functions inherited from TAttLine
	TAttLine ()
	AttLine default constructor.

	TAttLine (Color_t lcolor, Style_t lstyle, Width_t lwidth)
	AttLine normal constructor.

virtual	~TAttLine ()
	AttLine destructor.

void	Copy (TAttLine &attline) const
	Copy this line attributes to a new TAttLine.

Int_t	DistancetoLine (Int_t px, Int_t py, Double_t xp1, Double_t yp1, Double_t xp2, Double_t yp2)
	Compute distance from point px,py to a line.

virtual Color_t	GetLineColor () const
	Return the line color.

virtual Style_t	GetLineStyle () const
	Return the line style.

virtual Width_t	GetLineWidth () const
	Return the line width.

virtual void	Modify ()
	Change current line attributes if necessary.

virtual void	ResetAttLine (Option_t *option="")
	Reset this line attributes to default values.

virtual void	SaveLineAttributes (std::ostream &out, const char *name, Int_t coldef=1, Int_t stydef=1, Int_t widdef=1)
	Save line attributes as C++ statement(s) on output stream out.

virtual void	SetLineAttributes ()
	Invoke the DialogCanvas Line attributes.

virtual void	SetLineColor (Color_t lcolor)
	Set the line color.

virtual void	SetLineColorAlpha (Color_t lcolor, Float_t lalpha)
	Set a transparent line color.

virtual void	SetLineStyle (Style_t lstyle)
	Set the line style.

virtual void	SetLineWidth (Width_t lwidth)
	Set the line width.

void	StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

Static Public Member Functions
static TClass *	Class ()

static const char *	Class_Name ()

static constexpr Version_t	Class_Version ()

static const char *	DeclFileName ()

Static Public Member Functions inherited from TText
static TClass *	Class ()

static const char *	Class_Name ()

static constexpr Version_t	Class_Version ()

static const char *	DeclFileName ()

Static Public Member Functions inherited from TNamed
static TClass *	Class ()

static const char *	Class_Name ()

static constexpr Version_t	Class_Version ()

static const char *	DeclFileName ()

Static Public Member Functions inherited from TObject
static TClass *	Class ()

static const char *	Class_Name ()

static constexpr Version_t	Class_Version ()

static const char *	DeclFileName ()

static Longptr_t	GetDtorOnly ()
	Return destructor only flag.

static Bool_t	GetObjectStat ()
	Get status of object stat flag.

static void	SetDtorOnly (void *obj)
	Set destructor only flag.

static void	SetObjectStat (Bool_t stat)
	Turn on/off tracking of objects in the TObjectTable.

Static Public Member Functions inherited from TAttText
static TClass *	Class ()

static const char *	Class_Name ()

static constexpr Version_t	Class_Version ()

static const char *	DeclFileName ()

Static Public Member Functions inherited from TAttBBox2D
static TClass *	Class ()

static const char *	Class_Name ()

static constexpr Version_t	Class_Version ()

static const char *	DeclFileName ()

Static Public Member Functions inherited from TAttLine
static TClass *	Class ()

static const char *	Class_Name ()

static constexpr Version_t	Class_Version ()

static const char *	DeclFileName ()

Protected Member Functions
TLatexFormSize	Anal1 (const TextSpec_t &spec, const Char_t *t, Int_t length)
	Analyse function.

TLatexFormSize	Analyse (Double_t x, Double_t y, const TextSpec_t &spec, const Char_t *t, Int_t length)
	Analyse and paint the TLatex formula.

Int_t	CheckLatexSyntax (TString &text)
	Check if the Latex syntax is correct.

void	DrawCircle (Double_t x1, Double_t y1, Double_t r, const TextSpec_t &spec)
	Draw an arc of ellipse in a Latex formula (right or left parenthesis)

void	DrawLine (Double_t x1, Double_t y1, Double_t x2, Double_t y2, const TextSpec_t &spec)
	Draw a line in a Latex formula.

void	DrawParenthesis (Double_t x1, Double_t y1, Double_t r1, Double_t r2, Double_t phimin, Double_t phimax, const TextSpec_t &spec)
	Draw an arc of ellipse in a Latex formula (right or left parenthesis)

void	DrawPolyLine (Int_t npoints, Double_t xx, Double_t yy, const TextSpec_t &spec, Double_t scale_width=0.)
	Draw a poly line in a Latex formula Is scale_width parameter >=1, fill area will be drawn Otherwise line width will be scaled proportional to current font size If not specified - default line width will be used.

TLatexFormSize	FirstParse (Double_t angle, Double_t size, const Char_t *text)
	First parsing of the analyse sequence.

TLatex &	operator= (const TLatex &)
	assignment operator

Int_t	PaintLatex1 (Double_t x, Double_t y, Double_t angle, Double_t size, const char *text)
	Drawing function.

TLatexFormSize	Readfs ()
	Read fs in fTabSize.

void	Savefs (TLatexFormSize *fs)
	Save fs values in array fTabSize.

Protected Member Functions inherited from TObject
virtual void	DoError (int level, const char location, const char fmt, va_list va) const
	Interface to ErrorHandler (protected).

void	MakeZombie ()

Protected Attributes
const Char_t *	fError {nullptr}
	! error code

Double_t	fFactorPos
	! Relative position of subscripts and superscripts

Double_t	fFactorSize
	! Relative size of subscripts and superscripts

Bool_t	fItalic
	! Currently inside italic operator

Int_t	fLimitFactorSize
	lower bound for subscripts/superscripts size

Double_t	fOriginSize
	Font size of the starting font.

Bool_t	fShow
	! is true during the second pass (Painting)

std::vector< TLatexFormSize >	fTabSize
	! array of values for the different zones

Protected Attributes inherited from TText
void *	fWcsTitle {nullptr}
	!Used by TMathText

Double_t	fX {0}
	X position of text (left,center,etc..)

Double_t	fY {0}
	Y position of text (left,center,etc..)

Protected Attributes inherited from TNamed
TString	fName

TString	fTitle

Protected Attributes inherited from TAttText
Short_t	fTextAlign
	Text alignment.

Float_t	fTextAngle
	Text angle.

Color_t	fTextColor
	Text color.

Font_t	fTextFont
	Text font.

Float_t	fTextSize
	Text size.

Protected Attributes inherited from TAttLine
Color_t	fLineColor
	Line color.

Style_t	fLineStyle
	Line style.

Width_t	fLineWidth
	Line width.

Additional Inherited Members
Protected Types inherited from TObject
enum	{ kOnlyPrepStep = (1ULL << ( 3 )) }

#include <TLatex.h>

Inheritance diagram for TLatex:

[legend]

Member Enumeration Documentation

◆ anonymous enum

anonymous enum

Enumerator
kTextNDC	The text position is in NDC coordinates.

Definition at line 93 of file TLatex.h.

Constructor & Destructor Documentation

◆ TLatex() [1/3]

TLatex::TLatex ( )

Default constructor.

Definition at line 400 of file TLatex.cxx.

◆ TLatex() [2/3]

TLatex::TLatex	(	Double_t	x,
		Double_t	y,
		const char *	text
	)

Normal constructor.

Definition at line 415 of file TLatex.cxx.

◆ TLatex() [3/3]

TLatex::TLatex ( const TLatex & text )

Copy constructor.

Definition at line 438 of file TLatex.cxx.

◆ ~TLatex()

TLatex::~TLatex ( )

override

Destructor.

Definition at line 431 of file TLatex.cxx.

Member Function Documentation

◆ Anal1()

TLatex::TLatexFormSize TLatex::Anal1	(	const TextSpec_t &	spec,
		const Char_t *	t,
		Int_t	length
	)

protected

Analyse function.

Definition at line 490 of file TLatex.cxx.

◆ Analyse()

TLatex::TLatexFormSize TLatex::Analyse	(	Double_t	x,
		Double_t	y,
		const TextSpec_t &	spec,
		const Char_t *	t,
		Int_t	length
	)

protected

Analyse and paint the TLatex formula.

It is called twice : first for calculating the size of each portion of the formula, then to paint the formula. When analyse finds an operator or separator, it calls itself recursively to analyse the arguments of the operator. when the argument is an atom (normal text), it calculates the size of it and return it as the result. for example : if the operator #frac{arg1}{arg2} is found : Analyse(arg1) return the size of arg1 (width, up, down) Analyse(arg2) return the size of arg2 now, we know the size of #frac{arg1}{arg2}:

width = max(width_arg1, width_arg2)
up    = up_arg1 + down_arg1
down  = up_arg2 + down_arg2

so, when the user wants to paint a fraction at position (x,y), the rect used for the formula is : (x,y-up,x+width,y+down)

return size of zone occupied by the text/formula

t : chain to be analyzed
length : number of chars in t.

Definition at line 522 of file TLatex.cxx.

◆ CheckLatexSyntax()

Int_t TLatex::CheckLatexSyntax ( TString & text )

protected

Check if the Latex syntax is correct.

Definition at line 2322 of file TLatex.cxx.

◆ Class()

static TClass * TLatex::Class ( )

static

Returns: TClass describing this class

◆ Class_Name()

static const char * TLatex::Class_Name ( )

static

Returns: Name of this class

◆ Class_Version()

static constexpr Version_t TLatex::Class_Version ( )

inlinestaticconstexpr

Returns: Version of this class

Definition at line 118 of file TLatex.h.

◆ Copy()

void TLatex::Copy ( TObject & text ) const

overridevirtual

Copy this TLatex object to another TLatex.

Reimplemented from TObject.

Definition at line 473 of file TLatex.cxx.

◆ DeclFileName()

static const char * TLatex::DeclFileName ( )

inlinestatic

Returns: Name of the file containing the class declaration

Definition at line 118 of file TLatex.h.

◆ DrawCircle()

void TLatex::DrawCircle	(	Double_t	x1,
		Double_t	y1,
		Double_t	r,
		const TextSpec_t &	spec
	)

protected

Draw an arc of ellipse in a Latex formula (right or left parenthesis)

Definition at line 2030 of file TLatex.cxx.

◆ DrawLatex()

TLatex * TLatex::DrawLatex	(	Double_t	x,
		Double_t	y,
		const char *	text
	)

Make a copy of this object with the new parameters And copy object attributes.

Definition at line 1943 of file TLatex.cxx.

◆ DrawLatexNDC()

TLatex * TLatex::DrawLatexNDC	(	Double_t	x,
		Double_t	y,
		const char *	text
	)

Draw this TLatex with new coordinates in NDC.

Definition at line 1957 of file TLatex.cxx.

◆ DrawLine()

void TLatex::DrawLine	(	Double_t	x1,
		Double_t	y1,
		Double_t	x2,
		Double_t	y2,
		const TextSpec_t &	spec
	)

protected

Draw a line in a Latex formula.

Definition at line 2009 of file TLatex.cxx.

◆ DrawParenthesis()

void TLatex::DrawParenthesis	(	Double_t	x1,
		Double_t	y1,
		Double_t	r1,
		Double_t	r2,
		Double_t	phimin,
		Double_t	phimax,
		const TextSpec_t &	spec
	)

protected

Draw an arc of ellipse in a Latex formula (right or left parenthesis)

Definition at line 2060 of file TLatex.cxx.

◆ DrawPolyLine()

void TLatex::DrawPolyLine	(	Int_t	npoints,
		Double_t *	xx,
		Double_t *	yy,
		const TextSpec_t &	spec,
		Double_t	scale_width = `0.`
	)

protected

Draw a poly line in a Latex formula Is scale_width parameter >=1, fill area will be drawn Otherwise line width will be scaled proportional to current font size If not specified - default line width will be used.

Definition at line 1970 of file TLatex.cxx.

◆ FirstParse()

TLatex::TLatexFormSize TLatex::FirstParse	(	Double_t	angle,
		Double_t	size,
		const Char_t *	text
	)

protected

First parsing of the analyse sequence.

Definition at line 2521 of file TLatex.cxx.

◆ GetBoundingBox()

void TLatex::GetBoundingBox	(	UInt_t &	w,
		UInt_t &	h,
		Bool_t	angle = `kFALSE`
	)

overridevirtual

Return text size in pixels.

Reimplemented from TText.

Definition at line 2600 of file TLatex.cxx.

◆ GetHeight()

Double_t TLatex::GetHeight ( ) const

Return height of current pad in pixels.

Definition at line 2554 of file TLatex.cxx.

◆ GetXsize()

Double_t TLatex::GetXsize ( )

Return size of the formula along X in pad coordinates when the text precision is smaller than 3.

Definition at line 2569 of file TLatex.cxx.

◆ GetYsize()

Double_t TLatex::GetYsize ( )

Return size of the formula along Y in pad coordinates when the text precision is smaller than 3.

Definition at line 2657 of file TLatex.cxx.

◆ IsA()

TClass * TLatex::IsA ( ) const

inlineoverridevirtual

Returns: TClass describing current object

Reimplemented from TObject.

Definition at line 118 of file TLatex.h.

◆ operator=()

TLatex & TLatex::operator= ( const TLatex & lt )

protected

assignment operator

Definition at line 453 of file TLatex.cxx.

◆ Paint()

void TLatex::Paint ( Option_t * option = "" )

overridevirtual

Paint.

Reimplemented from TObject.

Definition at line 2092 of file TLatex.cxx.

◆ PaintLatex()

void TLatex::PaintLatex	(	Double_t	x,
		Double_t	y,
		Double_t	angle,
		Double_t	size,
		const char *	text
	)

virtual

Main drawing function.

Warning: Unlike most others "XYZ::PaintXYZ" methods, PaintLatex modifies the TLatex data members.

Definition at line 2114 of file TLatex.cxx.

◆ PaintLatex1()

Int_t TLatex::PaintLatex1	(	Double_t	x,
		Double_t	y,
		Double_t	angle,
		Double_t	size,
		const char *	text
	)

protected

Drawing function.

Definition at line 2207 of file TLatex.cxx.

◆ Readfs()

TLatex::TLatexFormSize TLatex::Readfs ( )

protected

Read fs in fTabSize.

Definition at line 2688 of file TLatex.cxx.

◆ Savefs()

void TLatex::Savefs ( TLatex::TLatexFormSize * fs )

protected

Save fs values in array fTabSize.

Definition at line 2703 of file TLatex.cxx.

◆ SavePrimitive()

void TLatex::SavePrimitive	(	std::ostream &	out,
		Option_t *	option = `""`
	)

overridevirtual

Save primitive as a C++ statement(s) on output stream out.

Reimplemented from TObject.

Definition at line 2711 of file TLatex.cxx.

◆ SetIndiceSize()

void TLatex::SetIndiceSize ( Double_t factorSize )

virtual

Set relative size of subscripts and superscripts.

Definition at line 2736 of file TLatex.cxx.

◆ SetLimitIndiceSize()

void TLatex::SetLimitIndiceSize ( Int_t limitFactorSize )

virtual

Set limit for text resizing of subscripts and superscripts.

Definition at line 2744 of file TLatex.cxx.

◆ Streamer()

void TLatex::Streamer ( TBuffer & R__b )

overridevirtual

Stream an object of class TObject.

Reimplemented from TObject.

◆ StreamerNVirtual()

void TLatex::StreamerNVirtual ( TBuffer & ClassDef_StreamerNVirtual_b )

inline

Definition at line 118 of file TLatex.h.

Member Data Documentation

◆ fError

const Char_t* TLatex::fError {nullptr}

protected

! error code

Definition at line 65 of file TLatex.h.

◆ fFactorPos

Double_t TLatex::fFactorPos

protected

! Relative position of subscripts and superscripts

Definition at line 63 of file TLatex.h.

◆ fFactorSize

Double_t TLatex::fFactorSize

protected

! Relative size of subscripts and superscripts

Definition at line 62 of file TLatex.h.

◆ fItalic

Bool_t TLatex::fItalic

protected

! Currently inside italic operator

Definition at line 69 of file TLatex.h.

◆ fLimitFactorSize

Int_t TLatex::fLimitFactorSize

protected

lower bound for subscripts/superscripts size

Definition at line 64 of file TLatex.h.

◆ fOriginSize

Double_t TLatex::fOriginSize

protected

Font size of the starting font.

Definition at line 68 of file TLatex.h.

◆ fShow

Bool_t TLatex::fShow

protected

! is true during the second pass (Painting)

Definition at line 66 of file TLatex.h.

◆ fTabSize

std::vector<TLatexFormSize> TLatex::fTabSize

protected

! array of values for the different zones

Definition at line 67 of file TLatex.h.

Libraries for TLatex:

[legend]

The documentation for this class was generated from the following files:

graf2d/graf/inc/TLatex.h
graf2d/graf/src/TLatex.cxx

Subscripts and Superscripts

Fractions

Splitting Lines

Roots

Mathematical Symbols

Delimiters

Greek Letters

Accents

Changing Style

Alignment Rules

Character Adjustment

Italic and Boldface

Examples

Interface to TMathText

Classes

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Member Enumeration Documentation

◆ anonymous enum

Constructor & Destructor Documentation

◆ TLatex() [1/3]

◆ TLatex() [2/3]

◆ TLatex() [3/3]

◆ ~TLatex()

Member Function Documentation

◆ Anal1()

◆ Analyse()

◆ CheckLatexSyntax()

◆ Class()

◆ Class_Name()

◆ Class_Version()

◆ Copy()

◆ DeclFileName()

◆ DrawCircle()

◆ DrawLatex()

◆ DrawLatexNDC()

◆ DrawLine()

◆ DrawParenthesis()

◆ DrawPolyLine()

◆ FirstParse()

◆ GetBoundingBox()

◆ GetHeight()

◆ GetXsize()

◆ GetYsize()

◆ IsA()

◆ operator=()

◆ Paint()

◆ PaintLatex()

◆ PaintLatex1()

◆ Readfs()

◆ Savefs()

◆ SavePrimitive()

◆ SetIndiceSize()

◆ SetLimitIndiceSize()

◆ Streamer()

◆ StreamerNVirtual()

Member Data Documentation

◆ fError

◆ fFactorPos

◆ fFactorSize

◆ fItalic

◆ fLimitFactorSize

◆ fOriginSize

◆ fShow

◆ fTabSize
