TGCompositeFrame Class Reference

The base class for composite widgets (menu bars, list boxes, etc.).

It provides:

  • a layout manager
  • a frame container (TList *)

Definition at line 287 of file TGFrame.h.

Public Member Functions

 TGCompositeFrame (const TGWindow *p=nullptr, UInt_t w=1, UInt_t h=1, UInt_t options=0, Pixel_t back=GetDefaultFrameBackground())
 Create a composite frame.

 TGCompositeFrame (TGClient *c, Window_t id, const TGWindow *parent=nullptr)
 Create a frame using an externally created window.

 ~TGCompositeFrame () override
 Delete a composite frame.

virtual void AddFrame (TGFrame *f, TGLayoutHints *l=nullptr)
 Add frame to the composite frame using the specified layout hints.

void ChangeOptions (UInt_t options) override
 Change composite frame options. Options is an OR of the EFrameTypes.

virtual void ChangeSubframesBackground (Pixel_t back)
 Change background color for this frame and all subframes.

virtual void Cleanup ()
 Cleanup and delete all objects contained in this composite frame.

virtual TGFrameElementFindFrameElement (TGFrame *f) const
 Find frame-element holding frame f.

UInt_t GetDefaultHeight () const override

TGDimension GetDefaultSize () const override
 std::cout << fWidth << "x" << fHeight << std::endl;

UInt_t GetDefaultWidth () const override

TGFrameGetFrameFromPoint (Int_t x, Int_t y) override
 Get frame located at specified point.

virtual TGLayoutManagerGetLayoutManager () const

virtual TListGetList () const

Int_t GetState (TGFrame *f) const
 Get state of sub frame.

Bool_t HandleButton (Event_t *) override

Bool_t HandleCrossing (Event_t *) override

Bool_t HandleDoubleClick (Event_t *) override

Bool_t HandleDragDrop (TGFrame *frame, Int_t x, Int_t y, TGLayoutHints *lo) override
 Handle drop event.

Bool_t HandleDragEnter (TGFrame *) override
 Handle drag enter event.

Bool_t HandleDragLeave (TGFrame *) override
 Handle drag leave event.

Bool_t HandleDragMotion (TGFrame *) override
 Handle drag motion event.

Bool_t HandleFocusChange (Event_t *) override

Bool_t HandleKey (Event_t *) override

Bool_t HandleMotion (Event_t *) override

Bool_t HandleSelection (Event_t *) override

virtual void HideFrame (TGFrame *f)
 Hide sub frame.

TClassIsA () const override

Bool_t IsArranged (TGFrame *f) const
 Get state of sub frame.

Bool_t IsArranged (TGFrameElement *ptr) const

Bool_t IsComposite () const override

Bool_t IsEditable () const override
 Return kTRUE if frame is being edited.

Bool_t IsLayoutBroken () const override

Bool_t IsMapSubwindows () const override

Bool_t IsVisible (TGFrame *f) const
 Get state of sub frame.

Bool_t IsVisible (TGFrameElement *ptr) const

void Layout () override
 Layout the elements of the composite frame.

void MapSubwindows () override
 Map all sub windows that are part of the composite frame.

Int_t MustCleanup () const override

void Print (Option_t *option="") const override
 Print all frames in this composite frame.

Bool_t ProcessMessage (Longptr_t, Longptr_t, Longptr_t) override

virtual void RemoveAll ()
 Remove all frames from composite frame.

virtual void RemoveFrame (TGFrame *f)
 Remove frame from composite frame.

void SavePrimitive (std::ostream &out, Option_t *option="") override
 Save a composite frame widget as a C++ statement(s) on output stream out.

virtual void SavePrimitiveSubframes (std::ostream &out, Option_t *option="")
 Auxiliary protected method used to save subframes.

void SetCleanup (Int_t mode=kLocalCleanup) override
 Turn on automatic cleanup of child frames in dtor.

void SetEditable (Bool_t on=kTRUE) override
 Switch ON/OFF edit mode.

void SetEditDisabled (UInt_t on=1) override
 Set edit disable flag for this frame and subframes.

void SetLayoutBroken (Bool_t on=kTRUE) override
 Set broken layout. No Layout method is called.

virtual void SetLayoutManager (TGLayoutManager *l)
 Set the layout manager for the composite frame.

void SetMapSubwindows (Bool_t on) override

virtual void ShowFrame (TGFrame *f)
 Show sub frame.

void Streamer (TBuffer &) override
 Stream an object of class TObject.

void StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

virtual Bool_t TranslateCoordinates (TGFrame *child, Int_t x, Int_t y, Int_t &fx, Int_t &fy)
 Translate coordinates to child frame.

- Public Member Functions inherited from TGFrame
 TGFrame (const TGWindow *p=nullptr, UInt_t w=1, UInt_t h=1, UInt_t options=0, Pixel_t back=GetDefaultFrameBackground())
 Create a TGFrame object. Options is an OR of the EFrameTypes.

 TGFrame (TGClient *c, Window_t id, const TGWindow *parent=nullptr)
 Create a frame using an externally created window.

 ~TGFrame () override
 Destructor.

virtual void Activate (Bool_t)

void AddInput (UInt_t emask)
 Add events specified in the emask to the events the frame should handle.

virtual void ChangeBackground (Pixel_t back)
 Change frame background color.

Bool_t Contains (Int_t x, Int_t y) const

void Delete (Option_t *="") override
 Delete this object.

virtual void DeleteWindow ()
 Delete window.

virtual void DrawBorder ()
 Draw frame border.

void DrawClass () const override
 Draw class inheritance tree of the class to which this object belongs.

TObjectDrawClone (Option_t *="") const override
 Draw a clone of this object in the current selected pad with: gROOT->SetSelectedPad(c1).

virtual void DrawCopy (Handle_t, Int_t, Int_t)

void Dump () const override
 Dump contents of object on stdout.

virtual Pixel_t GetBackground () const

Int_t GetBorderWidth () const

virtual TDNDDataGetDNDData (Atom_t)

virtual Int_t GetDragType () const
 Returns drag source type.

virtual Int_t GetDropType () const
 Returns drop target type.

UInt_t GetEventMask () const

virtual Pixel_t GetForeground () const
 Return frame foreground color.

TGFrameElementGetFrameElement () const

UInt_t GetHeight () const

UInt_t GetMaxHeight () const

UInt_t GetMaxWidth () const

UInt_t GetMinHeight () const

UInt_t GetMinWidth () const

virtual UInt_t GetOptions () const

TGDimension GetSize () const

UInt_t GetWidth () const

Int_t GetX () const

Int_t GetY () const

virtual Bool_t HandleClientMessage (Event_t *event)
 Handle a client message.

virtual Bool_t HandleColormapChange (Event_t *)

virtual Bool_t HandleConfigureNotify (Event_t *event)
 This event is generated when the frame is resized.

virtual Bool_t HandleDNDDrop (TDNDData *)

virtual Atom_t HandleDNDEnter (Atom_t *)

virtual Bool_t HandleDNDFinished ()

virtual Bool_t HandleDNDLeave ()

virtual Atom_t HandleDNDPosition (Int_t, Int_t, Atom_t, Int_t, Int_t)

Bool_t HandleEvent (Event_t *event) override
 Handle all frame events.

virtual Bool_t HandleSelectionClear (Event_t *)

virtual Bool_t HandleSelectionRequest (Event_t *)

void Inspect () const override
 Dump contents of this object in a graphics canvas.

TClassIsA () const override

virtual Bool_t IsActive () const

Bool_t IsDNDSource () const

Bool_t IsDNDTarget () const

Bool_t IsEditable () const override

void MapRaised () override
 map raised

void MapSubwindows () override
 map sub windows

void MapWindow () override
 map window

void Move (Int_t x, Int_t y) override
 Move frame.

void MoveResize (Int_t x, Int_t y, UInt_t w=0, UInt_t h=0) override
 Move and/or resize the frame.

void Print (Option_t *option="") const override
 Print window id.

virtual void ProcessedConfigure (Event_t *event)

virtual void ProcessedEvent (Event_t *event)

virtual void ReallyDelete ()

void RemoveInput (UInt_t emask)
 Remove events specified in emask from the events the frame should handle.

void ReparentWindow (const TGWindow *p, Int_t x=0, Int_t y=0) override
 Reparent window, make p the new parent and position the window at position (x,y) in new parent.

virtual void Resize (TGDimension size)
 Resize the frame.

void Resize (UInt_t w=0, UInt_t h=0) override
 Resize the frame.

void SavePrimitive (std::ostream &out, Option_t *option="") override
 Save a frame widget as a C++ statement(s) on output stream out.

void SaveUserColor (std::ostream &out, Option_t *)
 Save a user color in a C++ macro file - used in SavePrimitive().

virtual void SendMessage (const TGWindow *w, Longptr_t msg, Longptr_t parm1, Longptr_t parm2)
 Send message (i.e.

void SetBackgroundColor (Pixel_t back) override
 Set background color (override from TGWindow base class).

void SetDNDSource (Bool_t onoff)

void SetDNDTarget (Bool_t onoff)

virtual void SetDragType (Int_t type)
 SetDragType.

void SetDrawOption (Option_t *="") override
 Set drawing option for object.

virtual void SetDropType (Int_t type)
 SetDropType.

void SetEditable (Bool_t) override

virtual void SetForegroundColor (Pixel_t)

void SetFrameElement (TGFrameElement *fe)

virtual void SetHeight (UInt_t h)

virtual void SetMaxHeight (UInt_t h)

virtual void SetMaxWidth (UInt_t w)

virtual void SetMinHeight (UInt_t h)

virtual void SetMinWidth (UInt_t w)

virtual void SetSize (const TGDimension &s)

virtual void SetWidth (UInt_t w)

virtual void SetX (Int_t x)

virtual void SetY (Int_t y)

void Streamer (TBuffer &) override
 Stream an object of class TObject.

void StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

void UnmapWindow () override
 unmap window

- Public Member Functions inherited from TGWindow
 TGWindow (const TGWindow *p=nullptr, Int_t x=0, Int_t y=0, UInt_t w=0, UInt_t h=0, UInt_t border=0, Int_t depth=0, UInt_t clss=0, void *visual=nullptr, SetWindowAttributes_t *attr=nullptr, UInt_t wtype=0)
 Create a new window.

 TGWindow (TGClient *c, Window_t id, const TGWindow *parent=nullptr)
 Create a copy of a window.

 ~TGWindow () override
 Window destructor. Unregisters the window.

virtual void DestroySubwindows ()
 destroy sub windows

virtual void DestroyWindow ()
 destroy window

virtual UInt_t GetEditDisabled () const

virtual const TGWindowGetMainFrame () const
 Returns top level main frame.

const char * GetName () const override
 Return unique name, used in SavePrimitive methods.

const TGWindowGetParent () const

virtual Bool_t HandleExpose (Event_t *event)

virtual Bool_t HandleIdleEvent (TGIdleHandler *)

Bool_t HandleTimer (TTimer *) override
 Execute action in response of a timer timing out.

virtual void IconifyWindow ()
 iconify window

TClassIsA () const override

virtual Bool_t IsMapped ()
 Returns kTRUE if window is mapped on screen, kFALSE otherwise.

virtual void LowerWindow ()
 lower window

void Print (Option_t *option="") const override
 Print window id.

virtual void RaiseWindow ()
 raise window

virtual void RequestFocus ()
 request focus

virtual void SetBackgroundPixmap (Pixmap_t pixmap)
 set background pixmap

virtual void SetName (const char *name)

virtual void SetWindowName (const char *name=nullptr)
 Set window name.

void Streamer (TBuffer &) override
 Stream an object of class TObject.

void StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

- Public Member Functions inherited from TGObject
 TGObject ()

 TGObject (const TGObject &tgo)

 ~TGObject () override
 TGObject destructor.

TGClientGetClient () const

Handle_t GetId () const

ULong_t Hash () const override
 Return hash value for this object.

Bool_t IsEqual (const TObject *obj) const override
 Equal comparison (TGObjects are equal if they have the same window identifier).

void SaveAs (const char *filename="", Option_t *option="") const override
 Write this TGObject to a file using TImage, if filename's extension signals a valid TImage::EImageFileType, as defined by TImage::GetImageFileTypeFromFilename().

void StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

- Public Member Functions inherited from TObject
 TObject ()
 TObject constructor.

 TObject (const TObject &object)
 TObject copy ctor.

virtual ~TObject ()
 TObject destructor.

void AbstractMethod (const char *method) const
 Use this method to implement an "abstract" method that you don't want to leave purely abstract.

virtual void AppendPad (Option_t *option="")
 Append graphics object to current pad.

virtual void Browse (TBrowser *b)
 Browse object. May be overridden for another default action.

ULong_t CheckedHash ()
 Check and record whether this class has a consistent Hash/RecursiveRemove setup (*) and then return the regular Hash value for this object.

virtual const char * ClassName () const
 Returns name of class to which the object belongs.

virtual void Clear (Option_t *="")

virtual TObjectClone (const char *newname="") const
 Make a clone of an object using the Streamer facility.

virtual Int_t Compare (const TObject *obj) const
 Compare abstract method.

virtual void Copy (TObject &object) const
 Copy this to obj.

virtual Int_t DistancetoPrimitive (Int_t px, Int_t py)
 Computes distance from point (px,py) to the object.

virtual void Draw (Option_t *option="")
 Default Draw method for all objects.

virtual void Error (const char *method, const char *msgfmt,...) const
 Issue error message.

virtual void Execute (const char *method, const char *params, Int_t *error=nullptr)
 Execute method on this object with the given parameter string, e.g.

virtual void Execute (TMethod *method, TObjArray *params, Int_t *error=nullptr)
 Execute method on this object with parameters stored in the TObjArray.

virtual void ExecuteEvent (Int_t event, Int_t px, Int_t py)
 Execute action corresponding to an event at (px,py).

virtual void Fatal (const char *method, const char *msgfmt,...) const
 Issue fatal error message.

virtual TObjectFindObject (const char *name) const
 Must be redefined in derived classes.

virtual TObjectFindObject (const TObject *obj) const
 Must be redefined in derived classes.

virtual Option_tGetDrawOption () const
 Get option used by the graphics system to draw this object.

virtual const char * GetIconName () const
 Returns mime type name of object.

virtual char * GetObjectInfo (Int_t px, Int_t py) const
 Returns string containing info about the object at position (px,py).

virtual Option_tGetOption () const

virtual const char * GetTitle () const
 Returns title of object.

virtual UInt_t GetUniqueID () const
 Return the unique object id.

Bool_t HasInconsistentHash () const
 Return true is the type of this object is known to have an inconsistent setup for Hash and RecursiveRemove (i.e.

virtual void Info (const char *method, const char *msgfmt,...) const
 Issue info message.

virtual Bool_t InheritsFrom (const char *classname) const
 Returns kTRUE if object inherits from class "classname".

virtual Bool_t InheritsFrom (const TClass *cl) const
 Returns kTRUE if object inherits from TClass cl.

void InvertBit (UInt_t f)

Bool_t IsDestructed () const
 IsDestructed.

virtual Bool_t IsFolder () const
 Returns kTRUE in case object contains browsable objects (like containers or lists of other objects).

R__ALWAYS_INLINE Bool_t IsOnHeap () const

virtual Bool_t IsSortable () const

R__ALWAYS_INLINE Bool_t IsZombie () const

virtual void ls (Option_t *option="") const
 The ls function lists the contents of a class on stdout.

void MayNotUse (const char *method) const
 Use this method to signal that a method (defined in a base class) may not be called in a derived class (in principle against good design since a child class should not provide less functionality than its parent, however, sometimes it is necessary).

virtual Bool_t Notify ()
 This method must be overridden to handle object notification (the base implementation is no-op).

void Obsolete (const char *method, const char *asOfVers, const char *removedFromVers) const
 Use this method to declare a method obsolete.

void operator delete (void *ptr)
 Operator delete.

void operator delete[] (void *ptr)
 Operator delete [].

void * operator new (size_t sz)

void * operator new (size_t sz, void *vp)

void * operator new[] (size_t sz)

void * operator new[] (size_t sz, void *vp)

TObjectoperator= (const TObject &rhs)
 TObject assignment operator.

virtual void Paint (Option_t *option="")
 This method must be overridden if a class wants to paint itself.

virtual void Pop ()
 Pop on object drawn in a pad to the top of the display list.

virtual Int_t Read (const char *name)
 Read contents of object with specified name from the current directory.

virtual void RecursiveRemove (TObject *obj)
 Recursively remove this object from a list.

void ResetBit (UInt_t f)

void SetBit (UInt_t f)

void SetBit (UInt_t f, Bool_t set)
 Set or unset the user status bits as specified in f.

virtual void SetUniqueID (UInt_t uid)
 Set the unique object id.

void StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)

virtual void SysError (const char *method, const char *msgfmt,...) const
 Issue system error message.

R__ALWAYS_INLINE Bool_t TestBit (UInt_t f) const

Int_t TestBits (UInt_t f) const

virtual void UseCurrentStyle ()
 Set current style settings in this object This function is called when either TCanvas::UseCurrentStyle or TROOT::ForceStyle have been invoked.

virtual void Warning (const char *method, const char *msgfmt,...) const
 Issue warning message.

virtual Int_t Write (const char *name=nullptr, Int_t option=0, Int_t bufsize=0)
 Write this object to the current directory.

virtual Int_t Write (const char *name=nullptr, Int_t option=0, Int_t bufsize=0) const
 Write this object to the current directory.

- Public Member Functions inherited from TQObject
 TQObject ()
 TQObject Constructor.

virtual ~TQObject ()
 TQObject Destructor.

Bool_t AreSignalsBlocked () const

Bool_t BlockSignals (Bool_t b)

virtual void ChangedBy (const char *method)

void CollectClassSignalLists (TList &list, TClass *cls)
 Collect class signal lists from class cls and all its base-classes.

Bool_t Connect (const char *signal, const char *receiver_class, void *receiver, const char *slot)
 Non-static method is used to connect from the signal of this object to the receiver slot.

virtual void Connected (const char *)

virtual void Destroyed ()

Bool_t Disconnect (const char *signal=nullptr, void *receiver=nullptr, const char *slot=nullptr)
 Disconnects signal of this object from slot of receiver.

virtual void Disconnected (const char *)

void Emit (const char *signal)
 Activate signal without args.

template<typename T >
void Emit (const char *signal, const T &arg)
 Activate signal with single parameter.

template<typename... T>
void EmitVA (const char *signal_name, Int_t, const T &... params)
 Emit a signal with a varying number of arguments.

TListGetListOfClassSignals () const
 Returns pointer to list of signals of this class.

TListGetListOfConnections () const

TListGetListOfSignals () const

virtual Bool_t HasConnection (const char *signal_name) const
 Return true if there is any object connected to this signal.

virtual void HighPriority (const char *signal_name, const char *slot_name=nullptr)

virtual void LowPriority (const char *signal_name, const char *slot_name=nullptr)

virtual void Message (const char *msg)

virtual Int_t NumberOfConnections () const
 Return number of connections for this object.

virtual Int_t NumberOfSignals () const
 Return number of signals for this object.

void StreamerNVirtual (TBuffer &ClassDef_StreamerNVirtual_b)


Static Public Member Functions

static TClassClass ()

static const char * Class_Name ()

static constexpr Version_t Class_Version ()

static const char * DeclFileName ()

- Static Public Member Functions inherited from TGFrame
static TClassClass ()

static const char * Class_Name ()

static constexpr Version_t Class_Version ()

static const char * DeclFileName ()

static const TGGCGetBckgndGC ()
 Get background color graphics context.

static const TGGCGetBlackGC ()
 Get black graphics context.

static Pixel_t GetBlackPixel ()
 Get black pixel value.

static Pixel_t GetDefaultFrameBackground ()
 Get default frame background.

static Pixel_t GetDefaultSelectedBackground ()
 Get default selected frame background.

static const TGGCGetHilightGC ()
 Get highlight color graphics context.

static const TGGCGetShadowGC ()
 Get shadow color graphics context.

static const TGGCGetWhiteGC ()
 Get white graphics context.

static Pixel_t GetWhitePixel ()
 Get white pixel value.

- Static Public Member Functions inherited from TGWindow
static TClassClass ()

static const char * Class_Name ()

static constexpr Version_t Class_Version ()

static const char * DeclFileName ()

static Int_t GetCounter ()
 Return global window counter (total number of created windows).

- Static Public Member Functions inherited from TGObject
static TClassClass ()

static const char * Class_Name ()

static constexpr Version_t Class_Version ()

static const char * DeclFileName ()

- Static Public Member Functions inherited from TObject
static TClassClass ()

static const char * Class_Name ()

static constexpr Version_t Class_Version ()

static const char * DeclFileName ()

static Longptr_t GetDtorOnly ()
 Return destructor only flag.

static Bool_t GetObjectStat ()
 Get status of object stat flag.

static void SetDtorOnly (void *obj)
 Set destructor only flag.

static void SetObjectStat (Bool_t stat)
 Turn on/off tracking of objects in the TObjectTable.

- Static Public Member Functions inherited from TQObject
static Bool_t AreAllSignalsBlocked ()
 Returns true if all signals are blocked.

static Bool_t BlockAllSignals (Bool_t b)
 Block or unblock all signals. Returns the previous block status.

static TClassClass ()

static const char * Class_Name ()

static constexpr Version_t Class_Version ()

static Bool_t Connect (const char *sender_class, const char *signal, const char *receiver_class, void *receiver, const char *slot)
 This method allows to make a connection from any object of the same class to a single slot.

static Bool_t Connect (TQObject *sender, const char *signal, const char *receiver_class, void *receiver, const char *slot)
 Create connection between sender and receiver.

static const char * DeclFileName ()

static Bool_t Disconnect (const char *class_name, const char *signal, void *receiver=nullptr, const char *slot=nullptr)
 Disconnects "class signal".

static Bool_t Disconnect (TQObject *sender, const char *signal=nullptr, void *receiver=nullptr, const char *slot=nullptr)
 Disconnects signal in object sender from slot_method in object receiver.


Protected Attributes

Bool_t fLayoutBroken
 no layout manager is used

TGLayoutManagerfLayoutManager
 layout manager

TListfList
 container of frame elements

Bool_t fMapSubwindows
 kTRUE - map subwindows

Int_t fMustCleanup
 cleanup mode (see EFrameCleanup)

- Protected Attributes inherited from TGFrame
Pixel_t fBackground
 frame background color

Int_t fBorderWidth
 frame border width

Int_t fDNDState
 EDNDFlags.

UInt_t fEventMask
 currently active event mask

TGFrameElementfFE
 pointer to frame element

UInt_t fHeight
 frame height

UInt_t fMaxHeight
 maximal frame height

UInt_t fMaxWidth
 maximal frame width

UInt_t fMinHeight
 minimal frame height

UInt_t fMinWidth
 minimal frame width

UInt_t fOptions
 frame options

UInt_t fWidth
 frame width

Int_t fX
 frame x position

Int_t fY
 frame y position

- Protected Attributes inherited from TGWindow
UInt_t fEditDisabled
 flags used for "guibuilding"

TString fName
 name of the window used in SavePrimitive()

Bool_t fNeedRedraw
 kTRUE if window needs to be redrawn

const TGWindowfParent
 Parent window.

- Protected Attributes inherited from TGObject
TGClientfClient
 Connection to display server.

Handle_t fId
 X11/Win32 Window identifier.

- Protected Attributes inherited from TQObject
TListfListOfConnections
 list of signals from this object

TListfListOfSignals

Bool_t fSignalsBlocked
 list of connections to this object


Static Protected Attributes

static TGLayoutHintsfgDefaultHints = nullptr

- Static Protected Attributes inherited from TGFrame
static const TGGCfgBckgndGC = nullptr

static const TGGCfgBlackGC = nullptr

static Pixel_t fgBlackPixel = 0

static Window_t fgDbw = 0

static Int_t fgDbx = 0

static Int_t fgDby = 0

static Pixel_t fgDefaultFrameBackground = 0

static Pixel_t fgDefaultSelectedBackground = 0

static const TGGCfgHilightGC = nullptr

static Bool_t fgInit = kFALSE

static UInt_t fgLastButton = 0

static Time_t fgLastClick = 0

static const TGGCfgShadowGC = nullptr

static UInt_t fgUserColor = 0

static const TGGCfgWhiteGC = nullptr

static Pixel_t fgWhitePixel = 0

- Static Protected Attributes inherited from TGWindow
static Int_t fgCounter = 0
 counter of created windows in SavePrimitive

- Static Protected Attributes inherited from TQObject
static Bool_t fgAllSignalsBlocked = kFALSE
 flag used for suppression of signals


Private Member Functions

 TGCompositeFrame (const TGCompositeFrame &)=delete

TGCompositeFrameoperator= (const TGCompositeFrame &)=delete


Additional Inherited Members

- Public Types inherited from TGWindow
enum  EEditMode {
  kEditEnable = 0 , kEditDisable = (1ULL << ( 0 )) , kEditDisableEvents = (1ULL << ( 1 )) , kEditDisableGrab = (1ULL << ( 2 )) ,
  kEditDisableLayout = (1ULL << ( 3 )) , kEditDisableResize = (1ULL << ( 4 )) , kEditDisableHeight = (1ULL << ( 5 )) , kEditDisableWidth = (1ULL << ( 6 )) ,
  kEditDisableBtnEnable = (1ULL << ( 7 )) , kEditDisableKeyEnable = (1ULL << ( 8 ))
}

enum  EStatusBits { kIsHtmlView = (1ULL << ( 14 )) }

- Public Types inherited from TObject
enum  {
  kIsOnHeap = 0x01000000 , kNotDeleted = 0x02000000 , kZombie = 0x04000000 , kInconsistent = 0x08000000 ,
  kBitMask = 0x00ffffff
}

enum  { kSingleKey = (1ULL << ( 0 )) , kOverwrite = (1ULL << ( 1 )) , kWriteDelete = (1ULL << ( 2 )) }

enum  EDeprecatedStatusBits { kObjInCanvas = (1ULL << ( 3 )) }

enum  EStatusBits {
  kCanDelete = (1ULL << ( 0 )) , kMustCleanup = (1ULL << ( 3 )) , kIsReferenced = (1ULL << ( 4 )) , kHasUUID = (1ULL << ( 5 )) ,
  kCannotPick = (1ULL << ( 6 )) , kNoContextMenu = (1ULL << ( 8 )) , kInvalidObject = (1ULL << ( 13 ))
}

- Protected Types inherited from TGFrame
enum  { kDeleteWindowCalled = (1ULL << ( 15 )) }

- Protected Types inherited from TObject
enum  { kOnlyPrepStep = (1ULL << ( 3 )) }

- Protected Member Functions inherited from TGFrame
void DoRedraw () override
 Redraw the frame.

virtual void Draw3dRectangle (UInt_t type, Int_t x, Int_t y, UInt_t w, UInt_t h)
 Draw 3D rectangle on the frame border.

TString GetOptionString () const
 Returns a frame option string - used in SavePrimitive().

const TGResourcePoolGetResourcePool () const

void * GetSender () override

virtual void StartGuiBuilding (Bool_t on=kTRUE)
 Go into GUI building mode.

- Protected Member Functions inherited from TGWindow
 TGWindow (const TGWindow &tgw)

 TGWindow (Window_t id)

TGWindowoperator= (const TGWindow &tgw)

- Protected Member Functions inherited from TGObject
TGObjectoperator= (const TGObject &tgo)

- Protected Member Functions inherited from TObject
virtual void DoError (int level, const char *location, const char *fmt, va_list va) const
 Interface to ErrorHandler (protected).

void MakeZombie ()

- Protected Member Functions inherited from TQObject
virtual const char * GetSenderClassName () const

- Static Protected Member Functions inherited from TGFrame
static Time_t GetLastClick ()
 Get time of last mouse click.

- Static Protected Member Functions inherited from TQObject
static Int_t CheckConnectArgs (TQObject *sender, TClass *sender_class, const char *signal, TClass *receiver_class, const char *slot)
 Checking of consistency of sender/receiver methods/arguments.

static TString CompressName (const char *method_name)
 Removes "const" words and blanks from full (with prototype) method name and resolve any typedefs in the method signature.

static Bool_t ConnectToClass (const char *sender_class, const char *signal, TClass *receiver_class, void *receiver, const char *slot)
 This method allows to make connection from any object of the same class to the receiver object.

static Bool_t ConnectToClass (TQObject *sender, const char *signal, TClass *receiver_class, void *receiver, const char *slot)
 Create connection between sender and receiver.


#include <TGFrame.h>

Inheritance diagram for TGCompositeFrame:
[legend]

Constructor & Destructor Documentation

◆ TGCompositeFrame() [1/3]

TGCompositeFrame::TGCompositeFrame ( const TGCompositeFrame )
privatedelete

◆ TGCompositeFrame() [2/3]

TGCompositeFrame::TGCompositeFrame ( const TGWindow p = nullptr,
UInt_t  w = 1,
UInt_t  h = 1,
UInt_t  options = 0,
Pixel_t  back = GetDefaultFrameBackground()
)

Create a composite frame.

A composite frame has in addition to a TGFrame also a layout manager and a list of child frames.

Definition at line 861 of file TGFrame.cxx.

◆ TGCompositeFrame() [3/3]

TGCompositeFrame::TGCompositeFrame ( TGClient c,
Window_t  id,
const TGWindow parent = nullptr
)

Create a frame using an externally created window.

For example to register the root window (called by TGClient), or a window created via TVirtualX::InitWindow() (id is obtained with TVirtualX::GetWindowID()).

Definition at line 885 of file TGFrame.cxx.

◆ ~TGCompositeFrame()

TGCompositeFrame::~TGCompositeFrame ( )
override

Delete a composite frame.

Definition at line 904 of file TGFrame.cxx.

Member Function Documentation

◆ AddFrame()

void TGCompositeFrame::AddFrame ( TGFrame f,
TGLayoutHints l = nullptr
)
virtual

Add frame to the composite frame using the specified layout hints.

If no hints are specified default hints TGLayoutHints(kLHintsNormal,0,0,0,0) will be used. Most of the time, however, you will want to provide specific hints. User specified hints can be reused many times and need to be destroyed by the user. The added frames cannot not be added to different composite frames but still need to be deleted by the user.

Reimplemented in TGDockableFrame, TGFileContainer, TGPack, and TGSplitFrame.

Definition at line 1117 of file TGFrame.cxx.

◆ ChangeOptions()

void TGCompositeFrame::ChangeOptions ( UInt_t  options)
overridevirtual

Change composite frame options. Options is an OR of the EFrameTypes.

Reimplemented from TGFrame.

Definition at line 1043 of file TGFrame.cxx.

◆ ChangeSubframesBackground()

void TGCompositeFrame::ChangeSubframesBackground ( Pixel_t  back)
virtual

Change background color for this frame and all subframes.

Definition at line 1288 of file TGFrame.cxx.

◆ Class()

static TClass * TGCompositeFrame::Class ( )
static
Returns
TClass describing this class

◆ Class_Name()

static const char * TGCompositeFrame::Class_Name ( )
static
Returns
Name of this class

◆ Class_Version()

static constexpr Version_t TGCompositeFrame::Class_Version ( )
inlinestaticconstexpr
Returns
Version of this class

Definition at line 370 of file TGFrame.h.

◆ Cleanup()

void TGCompositeFrame::Cleanup ( )
virtual

Cleanup and delete all objects contained in this composite frame.

This will delete all objects added via AddFrame(). CAUTION: all objects (frames and layout hints) must be unique, i.e. cannot be shared.

Reimplemented in TGSplitFrame, and TGToolBar.

Definition at line 967 of file TGFrame.cxx.

◆ DeclFileName()

static const char * TGCompositeFrame::DeclFileName ( )
inlinestatic
Returns
Name of the file containing the class declaration

Definition at line 370 of file TGFrame.h.

◆ FindFrameElement()

TGFrameElement * TGCompositeFrame::FindFrameElement ( TGFrame f) const
virtual

Find frame-element holding frame f.

Definition at line 1094 of file TGFrame.cxx.

◆ GetDefaultHeight()

UInt_t TGCompositeFrame::GetDefaultHeight ( ) const
inlineoverridevirtual

Reimplemented from TGFrame.

Reimplemented in TGNumberEntry.

Definition at line 314 of file TGFrame.h.

◆ GetDefaultSize()

TGDimension TGCompositeFrame::GetDefaultSize ( ) const
inlineoverridevirtual

std::cout << fWidth << "x" << fHeight << std::endl;

Reimplemented from TGFrame.

Reimplemented in TGViewPort, TGGroupFrame, TGListBox, TGListTree, TGShutter, TGStatusBar, and TGView.

Definition at line 316 of file TGFrame.h.

◆ GetDefaultWidth()

UInt_t TGCompositeFrame::GetDefaultWidth ( ) const
inlineoverridevirtual

Reimplemented from TGFrame.

Reimplemented in TGLBContainer.

Definition at line 312 of file TGFrame.h.

◆ GetFrameFromPoint()

TGFrame * TGCompositeFrame::GetFrameFromPoint ( Int_t  x,
Int_t  y
)
overridevirtual

Get frame located at specified point.

Reimplemented from TGFrame.

Definition at line 1308 of file TGFrame.cxx.

◆ GetLayoutManager()

virtual TGLayoutManager * TGCompositeFrame::GetLayoutManager ( ) const
inlinevirtual

Reimplemented in TGNumberEntry, and TGTab.

Definition at line 338 of file TGFrame.h.

◆ GetList()

virtual TList * TGCompositeFrame::GetList ( ) const
inlinevirtual

Definition at line 310 of file TGFrame.h.

◆ GetState()

Int_t TGCompositeFrame::GetState ( TGFrame f) const

Get state of sub frame.

Definition at line 1218 of file TGFrame.cxx.

◆ HandleButton()

◆ HandleCrossing()

Bool_t TGCompositeFrame::HandleCrossing ( Event_t )
inlineoverridevirtual

Reimplemented from TGFrame.

Reimplemented in TRootContainer, TRootEmbeddedContainer, TGedNameFrame, TGListTree, TGTextEdit, TGTextView, and TGViewFrame.

Definition at line 326 of file TGFrame.h.

◆ HandleDoubleClick()

Bool_t TGCompositeFrame::HandleDoubleClick ( Event_t )
inlineoverridevirtual

◆ HandleDragDrop()

Bool_t TGCompositeFrame::HandleDragDrop ( TGFrame frame,
Int_t  x,
Int_t  y,
TGLayoutHints lo
)
overridevirtual

Handle drop event.

Reimplemented from TGFrame.

Definition at line 1421 of file TGFrame.cxx.

◆ HandleDragEnter()

Bool_t TGCompositeFrame::HandleDragEnter ( TGFrame )
overridevirtual

Handle drag enter event.

Reimplemented from TGFrame.

Definition at line 1365 of file TGFrame.cxx.

◆ HandleDragLeave()

Bool_t TGCompositeFrame::HandleDragLeave ( TGFrame )
overridevirtual

Handle drag leave event.

Reimplemented from TGFrame.

Definition at line 1395 of file TGFrame.cxx.

◆ HandleDragMotion()

Bool_t TGCompositeFrame::HandleDragMotion ( TGFrame )
overridevirtual

Handle drag motion event.

Reimplemented from TGFrame.

Definition at line 1413 of file TGFrame.cxx.

◆ HandleFocusChange()

Bool_t TGCompositeFrame::HandleFocusChange ( Event_t )
inlineoverridevirtual

Reimplemented from TGFrame.

Reimplemented in TGTextEdit, and TGHtml.

Definition at line 329 of file TGFrame.h.

◆ HandleKey()

Bool_t TGCompositeFrame::HandleKey ( Event_t )
inlineoverridevirtual

◆ HandleMotion()

Bool_t TGCompositeFrame::HandleMotion ( Event_t )
inlineoverridevirtual

◆ HandleSelection()

Bool_t TGCompositeFrame::HandleSelection ( Event_t )
inlineoverridevirtual

Reimplemented from TGFrame.

Reimplemented in TGMainFrame, TGTextEdit, and TGViewFrame.

Definition at line 330 of file TGFrame.h.

◆ HideFrame()

void TGCompositeFrame::HideFrame ( TGFrame f)
virtual

Hide sub frame.

Reimplemented in TGPack.

Definition at line 1190 of file TGFrame.cxx.

◆ IsA()

◆ IsArranged() [1/2]

Bool_t TGCompositeFrame::IsArranged ( TGFrame f) const

Get state of sub frame.

Definition at line 1244 of file TGFrame.cxx.

◆ IsArranged() [2/2]

Bool_t TGCompositeFrame::IsArranged ( TGFrameElement ptr) const
inline

Definition at line 352 of file TGFrame.h.

◆ IsComposite()

Bool_t TGCompositeFrame::IsComposite ( ) const
inlineoverridevirtual

Reimplemented from TGFrame.

Definition at line 353 of file TGFrame.h.

◆ IsEditable()

Bool_t TGCompositeFrame::IsEditable ( ) const
overridevirtual

Return kTRUE if frame is being edited.

Reimplemented from TGWindow.

Reimplemented in TGNumberEntry.

Definition at line 927 of file TGFrame.cxx.

◆ IsLayoutBroken()

Bool_t TGCompositeFrame::IsLayoutBroken ( ) const
inlineoverridevirtual

Reimplemented from TGFrame.

Definition at line 357 of file TGFrame.h.

◆ IsMapSubwindows()

Bool_t TGCompositeFrame::IsMapSubwindows ( ) const
inlineoverridevirtual

Reimplemented from TGWindow.

Definition at line 363 of file TGFrame.h.

◆ IsVisible() [1/2]

Bool_t TGCompositeFrame::IsVisible ( TGFrame f) const

Get state of sub frame.

Definition at line 1231 of file TGFrame.cxx.

◆ IsVisible() [2/2]

Bool_t TGCompositeFrame::IsVisible ( TGFrameElement ptr) const
inline

Definition at line 350 of file TGFrame.h.

◆ Layout()

void TGCompositeFrame::Layout ( )
overridevirtual

Layout the elements of the composite frame.

Reimplemented from TGFrame.

Reimplemented in TGContainer, TGViewPort, TGLBContainer, TGListBox, TGListTree, TGMdiDecorFrame, TGMenuBar, TGPack, TGShutter, TGTextView, and TGView.

Definition at line 1257 of file TGFrame.cxx.

◆ MapSubwindows()

void TGCompositeFrame::MapSubwindows ( )
overridevirtual

Map all sub windows that are part of the composite frame.

Reimplemented from TGWindow.

Reimplemented in TGPack, and TGPack.

Definition at line 1164 of file TGFrame.cxx.

◆ MustCleanup()

Int_t TGCompositeFrame::MustCleanup ( ) const
inlineoverridevirtual

Reimplemented from TGWindow.

Definition at line 360 of file TGFrame.h.

◆ operator=()

TGCompositeFrame & TGCompositeFrame::operator= ( const TGCompositeFrame )
privatedelete

◆ Print()

void TGCompositeFrame::Print ( Option_t option = "") const
overridevirtual

Print all frames in this composite frame.

Reimplemented from TObject.

Reimplemented in TGTextEdit.

Definition at line 1266 of file TGFrame.cxx.

◆ ProcessMessage()

◆ RemoveAll()

void TGCompositeFrame::RemoveAll ( )
virtual

Remove all frames from composite frame.

Reimplemented in TGContainer, TGComboBox, TGLBContainer, TGListBox, TRootIconBox, TSessionOutputFrame, and TSessionInputFrame.

Definition at line 1131 of file TGFrame.cxx.

◆ RemoveFrame()

void TGCompositeFrame::RemoveFrame ( TGFrame f)
virtual

Remove frame from composite frame.

Reimplemented in TGuiBldEditor, TGPack, TGSplitFrame, and TGuiBldNameFrame.

Definition at line 1149 of file TGFrame.cxx.

◆ SavePrimitive()

void TGCompositeFrame::SavePrimitive ( std::ostream &  out,
Option_t option = ""
)
overridevirtual

◆ SavePrimitiveSubframes()

void TGCompositeFrame::SavePrimitiveSubframes ( std::ostream &  out,
Option_t option = ""
)
virtual

Auxiliary protected method used to save subframes.

Definition at line 2667 of file TGFrame.cxx.

◆ SetCleanup()

void TGCompositeFrame::SetCleanup ( Int_t  mode = kLocalCleanup)
overridevirtual

Turn on automatic cleanup of child frames in dtor.

if mode = kNoCleanup - no automatic cleanup if mode = kLocalCleanup - automatic cleanup in this composite frame only if mode = kDeepCleanup - automatic deep cleanup in this composite frame and all child composite frames (hierarchical)

Attention! Hierarchical cleaning is dangerous and must be used with caution. There are many GUI components (in ROOT and in user code) which do not use Clean method in destructor ("custom deallocation"). Adding such component to GUI container which is using hierarchical cleaning will produce seg. violation when container is deleted. The reason is double deletion: first when Clean method is invoked, then at "custom deallocation". We are going to correct all ROOT code to make it to be consistent with hierarchical cleaning scheme.

Reimplemented from TGFrame.

Definition at line 1072 of file TGFrame.cxx.

◆ SetEditable()

void TGCompositeFrame::SetEditable ( Bool_t  on = kTRUE)
overridevirtual

Switch ON/OFF edit mode.

If edit mode is ON it is possible:

  1. embed other ROOT GUI application (a la ActiveX)

For example: TGMainFrame *m = new TGMainFrame(gClient->GetRoot(), 500, 500); m->SetEditable(); gSystem->Load("$ROOTSYS/test/Aclock"); // load Aclock demo Aclock a; gROOT->Macro("$ROOTSYS/tutorials/gui/guitest.C"); m->SetEditable(0); m->MapWindow();

Reimplemented from TGWindow.

Reimplemented in TRootContainer, and TRootEmbeddedContainer.

Definition at line 948 of file TGFrame.cxx.

◆ SetEditDisabled()

void TGCompositeFrame::SetEditDisabled ( UInt_t  on = 1)
overridevirtual

Set edit disable flag for this frame and subframes.

  • if (on & kEditDisable) - disable edit for this frame and all subframes.

Reimplemented from TGWindow.

Definition at line 1022 of file TGFrame.cxx.

◆ SetLayoutBroken()

void TGCompositeFrame::SetLayoutBroken ( Bool_t  on = kTRUE)
overridevirtual

Set broken layout. No Layout method is called.

Reimplemented from TGFrame.

Definition at line 1012 of file TGFrame.cxx.

◆ SetLayoutManager()

void TGCompositeFrame::SetLayoutManager ( TGLayoutManager l)
virtual

Set the layout manager for the composite frame.

The layout manager is adopted by the frame and will be deleted by the frame.

Reimplemented in TGListBox, TGShutter, and TGView.

Definition at line 1000 of file TGFrame.cxx.

◆ SetMapSubwindows()

void TGCompositeFrame::SetMapSubwindows ( Bool_t  on)
inlineoverridevirtual

Reimplemented from TGWindow.

Definition at line 362 of file TGFrame.h.

◆ ShowFrame()

void TGCompositeFrame::ShowFrame ( TGFrame f)
virtual

Show sub frame.

Reimplemented in TGPack.

Definition at line 1204 of file TGFrame.cxx.

◆ Streamer()

◆ StreamerNVirtual()

void TGCompositeFrame::StreamerNVirtual ( TBuffer ClassDef_StreamerNVirtual_b)
inline

Definition at line 370 of file TGFrame.h.

◆ TranslateCoordinates()

Bool_t TGCompositeFrame::TranslateCoordinates ( TGFrame child,
Int_t  x,
Int_t  y,
Int_t fx,
Int_t fy
)
virtual

Translate coordinates to child frame.

Definition at line 1332 of file TGFrame.cxx.

Member Data Documentation

◆ fgDefaultHints

TGLayoutHints * TGCompositeFrame::fgDefaultHints = nullptr
staticprotected

Definition at line 297 of file TGFrame.h.

◆ fLayoutBroken

Bool_t TGCompositeFrame::fLayoutBroken
protected

no layout manager is used

Definition at line 293 of file TGFrame.h.

◆ fLayoutManager

TGLayoutManager* TGCompositeFrame::fLayoutManager
protected

layout manager

Definition at line 291 of file TGFrame.h.

◆ fList

TList* TGCompositeFrame::fList
protected

container of frame elements

Definition at line 292 of file TGFrame.h.

◆ fMapSubwindows

Bool_t TGCompositeFrame::fMapSubwindows
protected

kTRUE - map subwindows

Definition at line 295 of file TGFrame.h.

◆ fMustCleanup

Int_t TGCompositeFrame::fMustCleanup
protected

cleanup mode (see EFrameCleanup)

Definition at line 294 of file TGFrame.h.

Libraries for TGCompositeFrame:

The documentation for this class was generated from the following files:
